DC COMPONENTS UF4004 Инструкция по эксплуатации онлайн
UF4001
THRU
UF4007
RECTIFIER SPECIALISTS
DC COMPONENTS CO., LTD.
FEATURES
* Low power loss, high efficiency
* Low forward voltage drop
* High current capability
* Ultra fast switching
* High surge capability
* High reliability
Maximum Average Forward Rectified Current
at T
A
= 50
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Instantaneous Forward Voltage at 1.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage T
A
= 25
o
C
Maximum Full Load Reverse Current
Average, Full Cycle .375*(9.5mm) lead length at T
L
= 55
o
C
Maximum Reverse Recovery Time (Note 1) trr
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
NOTES : 1. Test Conditions: IF = 0.5A, IR = 1.0A, IRR = 0.25A
2. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
C
J
T
J, TSTG
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
uAmps
nSec
pF
0
C
1.0
30
1.0 1.7
5.0
100
50 75
-65 to + 150
DO-41
Dimensions in inches and (millimeters)
UF4001 UF4002 UF4003 UF4004 UF4005 UF4006 UF4007
15
12
R
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
o
TECHNICAL SPECIFICATION OF ULTRA FAST RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 4.0 Amperes
DIA.
DIA.
.034(0.9)
.028(0.7)
1.0(25.4)
MIN.
.107(2.7)
.080(2.0)
.205(5.2)
.166(4.2)
1.0(25.4)
MIN.
www.dccomponents.com1REV-1,DEC,2015
* Lead: MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Mounting position: Any
* Weight: 2.08 grams
35 70 140 280 420 560 700
50 100 200 400 600 800 1000
50 100 200 400 600 800 1000
