General Outline ESIE07-05
1–4 Part 1 – System Outline
3
1
1
4
5
1.2 Technical Specifications: EWWD-CJYNN
Technical
specifications
The table below contains the technical specifications.
Model EWWD-CJYNN
Unit size 340 400 480 550 700 750 800
Cooling capacity (1) kW 334 399 462 510 666 735 792
Power input (1) kW 81 90 103 110 160 171 180
Screw compressor No. 1 1 1 1 2 2 2
Refrigerant circuits No. 1 1 1 1 2 2 2
Refrigerant charge R-134a kg 53 63 73 77 106 116 126
Oil charge l 14141414282828
Min % of capacity reduction % 25 25 25 25 12,5 12,5 12,5
Evaporator
Evaporators / water volume No./l 1/140 1/135 1/128 1/152 1/210 1/350 1/350
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5 10.5 10.5
Condenser
Condensers / water volume No./l 1/30 1/35 1/34 1/36 2/60 2/63 2/70
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5 10.5 10.5
Weight and dimensions (cond. 1 pass)
Standard unit shipping weight kg 1830 1855 1886 1965 3395 3495 3515
Standard unit operating weight kg 2000 2030 2050 2160 3640 3910 3940
Unit length mm 3310 3310 3310 3310 4300 4300 4300
Unit width mm 900 900 900 900 1290 1290 1290
Unit height mm 1970 1970 1970 1970 2070 2070 2070
Unit size 900 950 C10 C11 C12 C13
Cooling capacity (1) kW 871 934 1074 1139 1205 1268
Power input (1) kW 195 207 251 262 273 285
Screw compressor No.223333
Refrigerant circuits No.223333
Refrigerant charge R-134a kg 136 146 169 179 189 199
Oil charge l 282842424242
Min % of capacity reduction % 12.5 12.5 8.3 8.3 8.3 8.3
Evaporator
Evaporators / water volume No./l 1/350 1/350 1/350 1/350 1/415 1/415
Max operating pressure bar 16 16 16 16 16 16
Condenser
Condensers / water volume No./l 2/75 2/80 3/95 3/100 3/105 3/110
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5 10.5
Weight and dimensions (cond. 1 pass)
Standard unit shipping weight kg 3560 3590 4960 4980 5110 5135
Standard unit operating weight kg 3990 4020 5410 5430 5630 5660
Unit length mm 4300 4300 3770 3770 3770 3770
Unit width mm 1290 1290 2160 2160 2160 2160
Unit height mm 2070 2070 2320 2320 2320 2320
