ESIE07-05 General Outline
Part 1 – System Outline 1–15
3
1
4
5
Components The table below lists the components.
No. Component
1 Electrical panel
2 Power connections slot 150x260
3 4 holes Ø28 for isolator mounting
4 Evaporator water inlet (Øe 219.1 Victaulic connection)
5 Evaporator water outlet (Øe 219.1 Victaulic connection)
6 Condenser water inlet connection 5” gas
7 Condenser water outlet connection 5” gas
8 Circ. 1 condenser water connection
9 Circ. 2 condenser water connection
10 Circ. 3 condenser water connection
11 Compressors enclosure (optional)
