DC COMPONENTS S1A-DC Инструкция по эксплуатации онлайн
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TECHNICAL SPECIFICATIONS OF SURFACE MOUN
T
SILICON
RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts
CURRENT 1.0 Ampere
NOTES : 1. Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
2. Thermal Resistance (Junction to Ambient), .0.2x0.2in
2
(5x5mm
2
) copper pads to each terminal.
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at T
A
= 55
Peak Forward Surge Current I
FM
(surge): 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Junction Capacitance (Note 1)
Operating and Storage Temperature Range
SYMBOL
V
RRM
V
DC
I
O
I
FSM
C
J
T
J
, T
STG
V
RMS
Amps1.0
30
-65 to + 175
pF
0
C
UNITS
Volts
Volts
Typical Thermal Resistance
(Note 2)
12
Volts
Amps
30
0
C/W
RθJL
V
F
I
R
1.1
100
uAmps
Maximum Forward Voltage at 1.0A DC Volts
Maximum DC Reverse Current at
Rated DC Blocking Voltage
@T
A
= 25
o
C
@T
A
= 125
o
C
5.0
3. Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A.
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
S1A
THRU
S1M
FEATURES
* ldeal for surface mounted applications
* Low leakage current
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Mounting position: Any
* Weight: 0.093 gram
*Terminals: Solder plated, solderable per
MIL-STD-750, Method 2026
* Polarity: As marked
S1A S1B S1D S1G S1J S1K S1M
50 100 200 400 600 800 1000
35 70 140 280 420 560 700
50 100 200 400 600 800 1000
Maximum Reverse Recovery Time (Note 3)
trr
uSec
2.5
* Glass passivated junction
SMB(DO-214AA)
Dimensions in inches and (millimeters)
o
C
.155(3.9)
.130(3.3)
.185(4.7)
.160(4.1)
.083(2.1)
.075(1.9)
.012(0.30)
.006(0.15)
.008(0.21)
.002(0.05)
.220(5.6)
.196(5.0)
.060(1.5)
.030(0.8)
.096(2.4)
.084(2.1)
