DC COMPONENTS S3J-DC Инструкция по эксплуатации онлайн
S3A
THRU
S3M
Dimensions in inches and (millimeters)
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Operating and Storage Temperature Range
Volts
Amps
UNITS
Typical Thermal Resistance
(Note 2)
Maximum DC Reverse Current at Rated
DC Blocking Voltage
Maximum Instantaneous Forward Voltage at
3.0
A DC
µAmps
S3A S3B S3D S3G S3J S3K S3M
o
C/W
Typical Junction Capacitance (Note
1
)
pF
Maximum Average Forward Rectified Current
at T
A
= 75
o
C
o
C
Volts
Volts
Amps
Volts
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
@ TA=25
o
C
@ TA=100
o
C
35
50
50
70
100
100
140
200
200
280
400
400
420
600
600
560
800
800
700
1000
1000
3
.0
100
-55 to +150
20
1.1
5.0
60
50
T
J
,T
STG
Rθ
JL
C
J
I
R
SYMBOL
V
RRM
V
DC
I
O
I
FSM
V
RMS
V
F
SMC(DO-214AB)
.245(6.2)
.220(5.6)
.280(7.1)
.260(6.6)
.128(3.3)
.108(2.8)
.012(0.3)
.004(0.1)
.008(0.2)
.004(0.1)
.060(1.5)
.030(0.8)
.102(2.6)
.079(2.0)
.320(8.1)
.303(7.7)
REV-3,MAY,2017 www.dccomponents.com1
o
Note 1: Measured at 1 MHz and applied reverse voltage of 4.0 volts.
Note 2: Typical thermal resistance from junction to lead, with 0.28 x 0.28 in
2
(7 x 7 mm
2
) copper pads to each terminal.
* Ideal for surface mounted applications
* Glass passivated junction
* Low leakage current
* Low forward voltage drop
* High surge capability
FEATURES
MECHANICAL DATA
*Case: Molded plastic
* Epoxy: UL 94V-0 rated flame retardant
*Lead: MIL-STD-202E, Method 208 guaranteed
*Polarity: Color band denotes cathode end
* Mounting position: Any
*Weight: 0.093 gram approx.
TECHNICAL SPECIFICATIONS OF GENERAL PURPOSE SILICON RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 3.0 Amperes
