R
DC COMPONENTS CO., LTD.
RATING AND CHARACTERISTIC CURVES (GL34A THRU GL34M)
FIG. 1 - TYPICAL FORWARD CURRENT
DERATING CURVE
AVERAGE FORWARD CURRENT, (A)
Single Phase
Half Wave 60Hz
Resistive or
Inductive Load
AMBIENT TEMPERATURE, (
O
C)
0.5
.4
.3
.2
.1
0
0 25 50 75 100 125 150 175
FIG. 2 - MAXIMUM NON-REPETITIVE FOREARD
SURGE CURRENT
PEAK FORWARD SURGE CURRENT, (A)
NUMBER OF CYCLES AT 60Hz
0
100
10
20
30
40
50
8.3ms Single Half Sine-Wave
(JEDEC Method)
1 2 4 6 8 10 20 40 60 80
FIG. 3 - TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
INSTANTANEOUS FORWARD CURRENT, (A)
Pulse Width = 300us
1% Duty Cycle
TJ = 25
O
C
INSTANTANEOUS FORWARD VOLTAGE, (V)
.01
.1
1.0
10
.4 .6 .8 1.0 1.2 1.4 1.6
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT, (uA)
.01
.04
.1
.4
1.0
4
10
TJ = 100
O
C
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
0 20 20 20 20 100 120 140
TJ = 25
O
C
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
JUNCTION CAPACITANCE, (pF)
1
100
REVERSE VOLTAGE, (V)
.1 .2 .4 1.0 2 4 10 20 40 100
10
TJ = 25
O
C
www.dccomponents.com2REV-1,MARCH,2015
