DC COMPONENTS SS52F-DC Инструкция по эксплуатации онлайн
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
SK22
THRU
SK210
SMB ( DO-214AA )
.060(1.52)
.030(0.76)
.185(4.70)
.160(4.06)
.083(2.11)
.075(1.91)
.155(3.94)
.130(3.30)
.096(2.44)
.084(2.13)
.012(0.305)
.006(0.152)
.008(0.203)
.002(0.051)
.220(5.59)
.200(5.08)
@T
A
= 100
o
C
T
A
o
C
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SCHOTTKY BARRIER
VOLTAGE RANGE - 20 to 100 Volts CURRENT - 2.0
Amperes
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
NOTES : 1. Thermal Resistance (Junction to Ambient).
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
3. P.C.B Mounted with 0.2X0.2in (5.0X5.0mm
2
) copper pad area.
Maximum DC Reverse Current
at Rated DC Blocking Voltage
V
F
I
R
Maximum Instantaneous Forward Voltage at 2.0A DC Volts
1.0
20
@T
A
= 25
o
C
mAmps
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at Derating Lead Temperature
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
SYMBOL
V
RRM
V
DC
I
FSM
C
J
T
STG
V
RMS
UNITS
Volts
Volts
Volts
Amps
2.0
50
75
130
Amps
0
C/W
0
C
Storage Temperature Range
I
O
-55 to + 125
pF
Operating Temperature Range
T
J
-55 to + 150
0
C
Rθ
JA
0.55 0.70 0.85
FEATURES
* Glass passivated junction
* ldeal for surface mounted applications
* Low leakage current
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Mounting position: Any
* Weight: 0.093 gram
*Terminals: Solder plated solderable per
MIL-STD-750, Method 2026
* Polarity: As marked
2
Dimensions in inches and (millimeters)
=105
SK22 SK23 SK24 SK25 SK26 SK28 SK210
20 30 40 50 60 80 100
14 21 28 35 42 56 70
20 30 40 50 60 80 100
REV-1,Apr/25/2013
