www.DataSheet4U.com
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
SD820D
THRU
SD8100D
Dimensions in inches and (millimeters)
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SCHOTTKY BARRIER DIODE
VOLTAGE RANGE - 20 to 100 Volts CURRENT - 8.0 Amperes
FEATURES
MECHANICAL DATA
*Metal to silicon rectifier majority carrier conduction
*Low power loss, High efficiency
*High current capability
*Low forward voltage drop
*High surge capacity
* For use in low voltage high frequency inverters, free
wheeling, and polarity protection applications
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at T
C
=
100
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Typical Thermal Resistance (Note1)
Typical Junction Capacitance (Note 2)
SYMBOL
V
RRM
V
DC
I
FSM
C
J
T
J
, T
STG
V
RMS
UNITS
Volts
Volts
Volts
Amps
8.0
150
Amps
Storage Operating Temperature Range
Rθ
JA
I
O
-55 to + 150
pF
Maximum DC Reverse Current at
Rated DC Blocking Voltage
mAmps
Maximum Instantaneous Forward Voltage at 8.0A DC
5.0
50
@T
A
= 25
o
C
@T
A
= 100
o
C
60
700
30
21
30
0.65
Volts
0
C/W
0
C
SD820D SD830D
V
F
I
R
*Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
*Terminals: Solder plated, solderable per
MIL-STD-750, Method 2026
*Mounting position: Any
*Weight: 1.7 grams Approx.
SD840D SD850D SD860D SD880D SD8100D
20
14
20
40
28
40
50
35
50
60
42
60
80
56
80
100
70
100
0.75 0.85
Note : 1
. Mounted on PC Board with 14mm
2
(0.013mm thick) copper pad areas.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
TO-263(D
2
PAK)
.029(0.7)
.018(0.5)
.110(2.8)
.090(2.3)
.405(10.3)
.380(9.7)
.370(9.4)
.330(8.4)
.625(15.9)
.575(14.6)
.055
(1.4)
Max
.070(1.8)
.050(1.3)
6
o
~8
o
6
o
~8
o
.190(4.8)
.160(4.1)
.055(1.4)
.045(1.2)
.039(1.0)
.020(0.5)
.055(1.4)
.045(1.2)
0
o
~5
o
1 2 3
2
.100
(2.5)
Typ
23
