ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–49
3
2
4
5
1
Digital Inputs This screen shows the status of the reverse phase protection, high pressure switch and overcurrent
relay of the compressors in circuit 1.
Digital Inputs This screen shows the status of the fan overcurrent of each fanstep of circuit 1.
Remark: When the unit has standard ON/OFF fans, 3 fan steps are present. When the unit has
inverter and ON/OFF fans, only fan step 1 or 1 and 3 are present (depending on unit size).
Display Description
C1 REV. PH. PROT. Status of the reverse phase protection of circuit 1
C1 HIGH PR. SW. Status of the high pressure switch of circuit 1
INT. L. C11: C12 Status of the compressor interlock of compressors 1 and 2 of circuit 1
_
C1 REV.PH.PROT. :OK
C1 HIGH PR.SW. :OK
INT.L C11:OK C12:OK
DIGITAL INPUTS
Display Description
C1 FAN OVERC. ST1 Status of fan overcurrent of fanstep 1 of circuit 1
C1 FAN OVERC. ST2 Status of fan overcurrent of fanstep 2 of circuit 1
C1 FAN OVERC. ST3 Status of fan overcurrent of fanstep 3 of circuit 1
_
C1 FAN OVERC.ST1:OK
C1 FAN OVERC.ST2:OK
C1 FAN OVERC.ST3:NOK
DIGITAL INPUTS
