Sennheiser COMMAND HME 27 ATC/C3 300 ohm [3/4] Command 27 series

Sennheiser COMMAND HME 27 ATC/C3 300 ohm [3/4] Command 27 series
Product data
Headphones
HME 27 ATC/C3
300 ohm
HMD 27 ATC/C3
w. Std Boom
HMD 27 ATC/C3
w. 5 ohm Mic
HMD 27 ATC/C3
5 ohm w/o AG
HMD 27 ATC/C3
w/o AG
HME 27 S ATC/C3
Sound pressure level:
dB SPL @ 1 KHz, 0.5 V
94 +/- 3 94 +/- 3 94 +/- 3 94 +/- 3 94 +/- 3 94 +/- 3
dB SPL @ 1 KHz, 1 mW
95 +/- 3
95 +/- 3  +/-  95 +/- 3 95 +/- 3 95 +/- 3
dB SPL @ 1 KHz, 1V
100 +/- 3
100 +/- 3  +/-  100 +/- 3 100 +/- 3 100 +/- 3
Max SPL* [dB]
122 ActiveGard o
110 ActiveGard on
122 ActiveGard o
110 ActiveGard on
 ActiveGard o
 ActiveGard on
122 122 122 ActiveGard o
110 ActiveGard on
THD, total harmonic distortion
at 100 dB SPL at 1 kHz
< 1 % < 1 % < 1 % < 1 % < 1 % < 1 %
Frequency response 8-18,000 Hz 8-18,000 Hz 8-18,000 Hz 8-18,000 Hz 8-18,000 Hz 8-18,000 Hz
Impedance 300  300  300  300  300  300 
Microphone
Microphone type Electret Dynamic Dynamic Dynamic Dynamic Electret
Sensitivity /
Output voltage
Adjustable 17 – 100 mV/Pa.
Preset = 80 mV/Pa +0/-2 dB,
equals 800 mV +0/-2 dB
@ 114 dB SPL
0.5 mV/Pa @ 1 kHz 0.12 mV/Pa @ 1 kHz 0.12 mV/Pa @ 1 kHz 0.5 mV/Pa @ 1 kHz Adjustable 17 – 100 mV/Pa.
Preset = 80 mV/Pa +0/-2 dB,
equals 800 mV +0/-2 dB
@ 114 dB SPL
Pick-up pattern Figure-of-eight Cardioid Cardioid Cardioid Cardioid Figure-of-eight
Supply voltage 8-16 VDC N /A N /A N /A N /A 8-16 VDC
Frequency response 100–6,000 Hz 100–12,000 Hz 100–12,000 Hz 100–12,000 Hz 100–12,000 Hz 100–6,000 Hz
Impedance N /A 200  5  5  200  N /A
Recommended load resistance 150–2,200  N /A N /A N /A N /A 150–2,200 
* Limited by ActiveGard
®
3 / 4
COMMAND 27 Series
