Daikin EWADC16C-XS [5/96] Compressor asymmetric single screw

the latest high-

controller for infinitely modulating capacity from 100% to 25%. An integrated high efficiency oil separator

and standard start is Wye-Delta (Y-∆) type.

inside the tubes and water flowing outside. The tubes are enhanced for maximu

sealed.

The evaporators are single-pass on both the refrigerant and water sides for pure counter-

pressure drops. Both attributes contribute to the heat exchanger ef

victaulic kit (as standard). Each evaporator has 2 or 3 circuits, one for each compressor and is manufactured in accordance t

directive (PED).

The condenser is manufactured with internally enhanced

and mechanically expanded into lanced and rippled aluminum condenser fins with full fin collars. An integral sub-

steel brazed plates and manufactured in accordance to PED approval.

The material of the blades is glass reinforced resin and each fan is protected by a guard. Fan motors are protected by circuit breaker

(installed inside the electrical panel as a standard) and are IP54.

operating conditions and incorporate features like remote monitoring and diagnostics, the application of electronic expansion

becomes mandatory.

Electronic expansion valves possess unique features: short opening and closing time, high resolution, positive shut-

eliminate use of additional solenoid valve, continuous modulation of mass flow without stress in the refrigerant circuit and

problems and with a perfect chilled water leaving temperature control.

Each unit has 2 or 3 independent refrigerant circuits and each one includes:

• Compressor with integrated oil separator

• Refrigerant

• Evaporator

• Air Cooled Condenser

• Electronic expansion valve

• Discharge line shut off valve

• Low pressure transducers

• Oil pressure transducer
