ESIE 05-07 The Digital Controller For Large chillers
Part 2 – Functional Description 2–119
3
2
4
5
1
Screen 6a This screen shows extra information about the compressor running hours for heat pump units:
Screen 7 and 8 These screens show information about the EEV and will therefore only be visible if electronic
expansion valves are present.
Remark: This screen is only visible if the parameter SCREENS is put on Yes (see EEV service menu
on page 2–141)
Line n° Display Description
1 EXTRA READ-OUT Compressor running hours.
2.1 C1C: h Total running hours of compressor 1 in cooling mode.
2.2 H: h Total running hours of compressor 1 in heating mode.
3.1 C2C: h Total running hours of compressor 2 in cooling mode.
3.2 H: h Total running hours of compressor 2 in heating mode.
Line n° Display Description
1 EEV 1 (2) READ-OUT Read-out off EEV driver of circuit 1 or 2
2 SUCTION TEMP: Actual suction temperature (unity: 0.1°C)
3 SUPERHEAT: Actual superheat temperature (unity: 0.1°C)
