OLIMEX© 2015 A20-SOM user's manual
CHAPTER 6: CONNECTORS AND PINOUT
6. Introduction to the chapter
In this chapter are presented the connectors that can be found on the board all together with their
pinout and notes about them. Jumpers functions are described. Notes and info on specific
peripherals are presented. Notes regarding the interfaces are given.
6.1 Communication with A20-SOM in Linux
The direct access method to the Linux command interface is via the serial interface. You would
need to use the pins of the UART0 and then use your favorite terminal program (puTTy, minicom,
picocom, teraterm, etc) to access the command line interface of the debian the data/send commands.
You can use USB-SERIAL-CABLE-F with the UART0 interface that allows you to connect to a
personal computer with a free USB port.
If you decide to make your own cable you would need to consider that the levels at board's UART0
are in CMOS level (3.3V) and you would need a convertor to bring them to the TTL level of your
computer or cable! That is true for the RX and TX also!
It is highly recommended to have an USB-SERIAL-CABLE-F (or similar product) at hand when
debugging – the video output is not always reliable and if you set wrong display settings you might
be unable to recover the settings without a proper UART0 connection.
For more information please refer to chapter “2.5 Interacting with the board”.
6.2 UART0 pins
The UART0 interface might be used for serial communication between the board and a personal
computer by default. In the case of a video output problem a cable might provide the needed
feedback and greatly reduce the efforts needed to repair the board or to adjust the software setting.
Note that by default only UART0 is defined as a port suitable for serial debug. You can use our
USB-SERIAL-CABLE-F for debugging.
Even when A20-SOM is mounted on A20-SOM-EVB the default debug port remains UART0
(despite that it gets additional pins on the big board also for easier access).
UART0
Pin # Signal name Processor pin
1 UART0-TX A7
2 UART0-RX B7
3 GND -POWER CIRCUIT-
4 GND -POWER CIRCUIT-
5 5VEXT -POWER CIRCUIT-
Page 22 of 41
