OLIMEX© 2015 IMX233-OLinuXino-MAXI user's manual
GPIO connector hardware
GPIO
Pin#
Signal Name Processor pin#
GPIO
Pin#
Signal Name Processor pin#
1 BAT 103 21 PIN8/LCD_D07 9
2 GND
30, 35, 98,
105, 112, 118
22 PIN27/PWM2 91
3 PIN17/LCD_D16 19 23 PIN7/LCD_D06 8
4 PIN18/LCD_D17/LAN_RES 20 24 PIN28/SOFT_SDA 31
5 PIN16/LCD_D15 28 25 PIN6/LCD_D05 7
6 PIN19/LCD_DOTCLK 17 26 PIN29/SOFT_SCL 34
7 PIN15/LCD_D14 29 27 PIN5/LCD_D04 6
8 PIN20/LCD_VSYNC 16 28 PIN30 81
9 PIN14/LCD_D13 26 29 PIN4/LCD_D03 5
10
PIN21/LCD_HSYNC/
I2C_SDA
15 30 PIN31 82
GPIO
Pin#
Name Processor pin#
GPIO
Pin#
Name Processor pin#
11 PIN13/LCD_D12 27 31 PIN3/LCD_D02 4
12 PIN22/LCD_EN/I2C_SCL 11 32 PIN32/LRADC1 107
13 PIN12/LCD_D11/UEXT_CS 25 33 PIN2/LCD_D01 3
14 PIN23/LCD_DISP 12 34 PIN33/LRADC0 108
15 PIN11/LCD_D10 24 35 PIN1/LCD_D00 2
16 PIN24/LCD_WR 13 36 PIN34/MIC 116
17 PIN10/LCD_D09 23 37 +5VUEXT 102
18 PIN25/LCD_RS 14 38 3.3VREG -
19
PIN9/LCD_D08/
SSP2_MISO
22 39 VIN -
20 PIN26/LCD_CS 10 40 GND
30, 35, 98,
105, 112, 118
The hardware is associated differently in the Linux following the GPIO naming conventions
suggested in the iMX233 datasheet. You can check the connection between Linux naming of the
pin, Olimex naming of the pin and the consecutive connector pin number in the table below. The
ones filled with “Not implemented” doesn't have Linux support by the time of writing and will be
updated overtime. “Linux GPIO” is the one you should use in Linux (the one in the datasheet);
“OLinuXino name” is the pin as written on the bottom of the board. ”OLinuXino GPIO Connector
Page 38 of 59
