OLIMEX IMX233-NANO+I [11/36] How to use the i2c spi uart

below. These guides are not created nor tested by Olimex, however, they are worth a look:

https://github.com/koliqi/imx23-olinuxino

http://eewiki.net/display/linuxonarm/iMX233-OLinuXino

http://www.jann.cc/2012/08/23/building_a_kernel_3_x_for_the_olinuxino_from_sources.html

2.7 How to use the I2C, SPI, UART

There are number of examples with our extension module boards to achieve the mentioned

interfaces using the UEXT connector. The examples might be used as examples for I2C, SPI or

UART communication. You can find them at our GitHub page:

https://github.com/OLIMEX/OLINUXINO/tree/master/SOFTWARE/iMX233

Page 11 of 36
