OLIMEX© 2017 RT5350F-OLinuXino user's manual
CHAPTER 1: OVERVIEW
1. Introduction to the chapter
Thank you for choosing this single-board computer from Olimex! This document provides a user’s
guide for the RT5350F-OLinuXino and RT5350F-OLinuXino-EVB boards. As an overview, this
chapter gives the scope of this document and lists the board’s features. The document’s organization
is then detailed.
The RT5350F-OLinuXino development board enables code development of applications running on
the RT5350F SoC microcontroller, manufactured by Ralink (a MediaTek's subsidiary company)
from Taiwan.
The RT5350F-OLinuXino is typically used together with RT5350F-OLinuXino-EVB which
features most of the peripherals and connectors needed for evaluation and utilization of the RT5350
SoC.
The hardware designs of RT5350F-OLinuXino and RT5350F-OLinuXino-EVB board are open-
source, open-hardware and all documentation used for the hardware design and manufacturing is
available to the customer.
The software written by Olimex for both boards is also open-source and released under GPL
license.
1.1 Introduction to system-on-a-module design
The design of both RT5350F-OLinuXino and RT5350F-OLinuXino-EVB follows the system-on-a-
module approach. A low-cost modular design which allows rapid product development and
integration in own products. It is a two part system – a main part (smaller, multilayer, very densely
populated) that nests the processor, the memory, the power control unit and a peripheral part (bigger
and less densely populated) which contains the USB ports, the Ethernet connectors, most of the
other connectors and interfaces. SOM designs are targeted at customers who want to apply custom
modifications for own projects without having to deal with multilayer PCBs with controlled
impedance and BGA assembly. This modular approach makes it possible to create simple 2-layer
boards (that can be manufactured by your local PCB manufacturer) containing only the peripherals
you need with the dimensions and shape suitable for your specific case.
Both the main part and the peripheral part of the SOM system have support in the official
OpenWRT images distributed by Olimex and maintained by Olimex. These recommended images
are typically available at the wiki articles of the board. Furthermore, the OpenWRT community
recognizes the board and also provides official builds.
The hardware designs of both RT5350F-OLinuXino and RT5350F-OLinuXino-F are open source,
unlike other Olimex SOM designs (where the design layout of the densely populated part is
propriety).
