SINOVOIP BANANA-PI-M1+ [23/110] Bpi m1 rgb dsi interface

BPI-M1RGBDSIinterface

RGBDSI(DisplaySerialInterface)：

ThedisplayConnectorisa40-pinFPCconnectorwhichcanconnectexternalLCDpanel(RGBDSI)andtouchscreen

(I2C)moduleaswell.Thepindefinitionsofthisconnectorareshownasbelow.ThisismarkedontheBananaPiboardas

“DSI”.

DSIpindefine:

pleasesee:BPI-M1GPIOpinedefine

BPI-M1LCDtouchpanelaccessories
