Daikin EWAQ260E-XL [12/34] Electrical specifications
![Daikin EWAQ260E-XL [12/34] Electrical specifications](/views2/1661364/page12/bgc.png)
ELECTRICAL SPECIFICATIONS
EWAQ E-XL
200 230 260 320 340 180 MODEL
POWER SUPPLY
Phases Nr 3 3 3 3 3 3
Frequency
Hz
50
50
50
50
50
50
Voltage V 400 400 400 400 400 400
Voltage tolerance Minimum % -10% -10% -10% -10% -10% -10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
UNIT
Maximum starting current A 384 482 500 447 563 577
Nominal running current cooling
A
103
115
129
151
179
190
Mximum running current
A
133
147
165
195
227
241
Maximum current for wires sizing A 146 162 181 215 250 265
FANS
Nominal running current cooling
A
16
16
20
20
24
24
COMPRESSORS
Phases Nr 3 3 3 3 3 3
Voltage V 400 400 400 400 400 400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10%
Maximum running current
A
117
131
145
175
203
217
Starting method --- DOL DOL DOL DOL DOL DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: starting current of biggest compressor + current of the other compressors at maximum load + fans current at maximum load
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
Pagina 12 di 34
