Daikin EWAQ220E-XR [13/34] Electrical specifications
![Daikin EWAQ220E-XR [13/34] Electrical specifications](/views2/1661364/page13/bgd.png)
ELECTRICAL SPECIFICATIONS
EWAQ E-XR
190 220 260 300 320 170 MODEL
POWER SUPPLY
Phases Nr 3 3 3 3 3 3
Frequency
Hz
50
50
50
50
50
50
Voltage V 400 400 400 400 400 400
Voltage tolerance Minimum % -10% -10% -10% -10% -10% -10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
UNIT
Maximum starting current A 379 477 493 440 554 568
Nominal running current cooling
A
101
113
127
151
179
189
Mximum running current
A
127
141
158
188
219
233
Maximum current for wires sizing A 140 155 174 207 241 256
FANS
Nominal running current cooling
A
10
10
13
13
16
16
COMPRESSORS
Phases Nr 3 3 3 3 3 3
Voltage V 400 400 400 400 400 400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10%
Maximum running current
A
117
131
145
175
203
217
Starting method --- DOL DOL DOL DOL DOL DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: starting current of biggest compressor + current of the other compressors at maximum load + fans current at maximum load
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
