INSTALLATION NOTES
Acoustic protection
When noise level must meet special requirements, it is necessary to pay the maximum attention to ensure
the perfect insulation of the unit from the support base by applying appropriate vibration-
dampening devices on the unit, on the water
pipes and on the electrical connections.
Storage
The environment conditions have to be in the following limits:
Minimum ambient temperature:
Maximum ambient temperature:
Maximum R.H.:
-20°C
+42°C
95% not condensing
Pagina 30 di 34
