D - EIMWC01006-11EU - 4/192
ENGLISH - ORIGINAL INSTRUCTIONS
This manual is an important supporting document for qualified personnel but it is not intended to replace such personnel.
EWWD120J-SS ~ 280J-SS
EWLD 110J-SS ~ 265J-SS
EWWD310J-SS ~ 560J-SS
EWLD 290J-SS ~ 530J-SS
Label Identification
1
– Unit nameplate data
5
– Manufacturer’s logo
2
– Lifting instructions
6
– Emergency stop
3
– Hazardous Voltage warning
7
– Non flammable gas symbol
4
– Electrical hazard symbol
8
– Gas type
