• Single Unit • Чиллер с водяным охлаждением, стандартная эффективность • EWWD-J-SS
1
6
• Hydronic Systems • Single Unit14
6 Таблицы производительности
6 - 2 Таблицы холодопроизводител ьности
EWWD120-310J-SS
SRC_1-2_Rev.01_2_(1_6)
Twe: Evaporator leaving water temperature (ǻt 5°C); Twc: Condenser leaving water temperature (ǻt 5°C);
CC: Cooling capacity; PI: Power input; qwe: Fluid flow rate at evaporator; dpwe: Fluid pressure drop at evaporator;
HC: Heat capacity at condenser; qwc: Fluid flow rate at condenser; dpwc: Fluid pressure drop at condenser
Twc
Twe
579
CC PI qwe
dpwe
HC qwc
dpwc
CC PI qwe
dpwe
HC qwc
dpwc
CC PI qwe
dpwe
HC qwc
dpwc
Size
kW kW l/s kPa kW l/s kPa kW kW l/s kPa kW l/s kPa kW kW l/s kPa kW l/s kPa
120
30 117 24.9 5.6 14 141 6.8 18 125 25.5 6.0 16 150 7.2 20 133 26.2 6.4 18 159 7.6 22
35 112 27.3 5.3 13 139 6.7 17 120 28.0 5.7 15 147 7.1 19 128 28.7 6.1 17 156 7.5 21
40 107 30.0 5.1 12 136 6.6 17 114 30.6 5.5 14 145
7.0 19
122 31.3 5.9 16 153
7.4 21
45 101 32.8 4.8 11 134 6.5 16 109 33.5 5.2 13 142
6.9 18
116 34.2 5.6 14 150
7.3 20
50 95.4 36.0 4.6 10 131 6.4 16 103 36.7 4.9 11 139 6.7 18 110 37.4 5.3 13 147 7.1 19
55 89.4 39.4 4.3 9 128 6.2 15 96.2 40.1 4.6 10 136 6.6 17 103 40.8 5.0 12 144 7.0 19
140
30 142 30.2 6.8 13 172 8.3 11 152 31.0 7.3 15 183 8.8 13 162 31.9 7.8 17 194
9.3 14
35 136 33.2 6.5 12 169 8.1 11 146 34.0 7.0 14 179 8.6 12 156 34.8 7.5 16 190 9.2 14
40 130 36.4 6.2 11 166 8.0 11 139 37.2 6.6 13 176
8.5 12
149 38.1 7.1 15 187 9.0 13
45 123 39.9 5.9 10 163 7.9 10 132 40.7 6.3 12 172
8.3 11
142 41.6 6.8 13 183 8.8 13
50 116 43.7 5.5 9 159 7.7 10 125 44.6 6.0 11 169 8.2 11 134 45.4 6.4 12 179 8.7 12
55 108 47.9 5.2 8 156 7.6 10 117 48.7 5.6 9 165 8.0 11 126 49.6 6.0 11 175
8.5 12
150
30 151 35.2 7.2 41 186
8.9 11
160 36.0 7.7 46 196
9.4 12
169 36.8 8.1 51 206
9.9 13
35 145 38.7 7.0 38 184 8.9 10 154 39.5 7.4 43 193 9.3 12 163 40.4 7.8 48 203 9.8 13
40 139 42.5 6.7 35 181 8.8 10 148 43.3 7.1 40 191 9.2 11 157 44.2 7.5 44 201 9.7 12
45 132 46.6 6.3 32 179 8.6 10 142 47.5 6.8 37 189 9.1 11 150 48.4 7.2 41 198 9.6 12
50 125 51.1 6.0 29 176 8.5 10 134 52.0 6.4 33 186 9.0 11 143 52.9 6.9 38 196 9.5 12
55 118 56.0 5.6 26 174
8.4 9
126 56.9 6.0 30 183
8.9 10
135 57.8 6.5 34 193
9.4 11
180
30 173 40.3 8.3 38 213
10.3 11
184 41.3 8.8 43 225
10.8 12
195 42.3 9.4 48 237
11.4 13
35 167 44.3 8.0 36 211 10.2 11 177 45.3 8.5 40 222 10.7 12 188 46.3 9.0 45 234 11.3 13
40 159 48.6 7.6 33 208 10.0 10 170 49.6 8.1 37 219 10.6 11 181 50.7 8.7 42 231 11.2 12
45 151 53.4 7.2 30 205 9.9 10 162 54.4 7.8 34 216 10.5 11 173 55.4 8.3 38 228 11.0 12
50 143 58.5 6.9 27 202 9.8 10 153 59.5 7.3 31 213 10.3 11 164 60.6 7.9 35 224 10.9 12
55 135 64.2 6.5 25 199
9.7 10
144 65.1 6.9 28 209
10.2 10
155 66.2 7.4 31 220
10.7 11
210
30 203 45.0 9.7 34 247
11.9 10
215 46.0 10.3 38 261
12.5 11
228 47.1 10.9 42 275
13.2 13
35 195 49.4 9.3 32 244 11.8 10 207 50.4 9.9 35 257 12.4 11 220 51.5 10.5 39 271 13.1 12
40 186 54.1 8.9 29 240 11.6 10 199 55.2 9.5 33 254 12.3 11 211 56.3 10.1 37 267 12.9 12
45 177 59.5 8.5 27 236 11.4 10 189 60.6 9.1 30 249 12.1 11 202 61.7 9.7 34 263 12.7 12
50 167 65.6 8.0 24 232 11.2 9 178 66.7 8.5 27 244 11.8 10 190 67.9 9.1 30 257 12.5 11
55 153 72.6 7.3 20 225
10.9 9
164 73.8 7.9 23 238
11.6 10
176 75.0 8.4 26 250
12.2 11
250
30
250 52.6 11.9 27 302
14.5 15
266 53.2 12.7 30 319
15.3 16
282 53.9 13.5 34 335
16.1 18
35 239 59.1 11.4 25 298 14.4 15 255 59.9 12.2 28 315 15.2 16 272 60.8 13.0 32 332 16.0 18
40 228 66.2 10.9 23 294 14.2 14 244 67.1 11.7 26 311 15.0 16 260 68.0 12.5 29 327 15.8 17
45 217 73.9 10.4 21 291 14.1 14 232 74.8 11.1 24 307 14.8 16 248 75.7 11.9 27 323 15.6 17
50 205 82.1 9.8 19 287 13.9 14 220 83.0 10.5 22 302 14.7 15 235 84.0 11.3 24 318 15.4 17
55 193 91.0 9.2 17 283
13.8 14
207 91.9 9.9 19 298
14.5 15
221 92.9 10.6 22 314
15.2 16
280
30 279 61.4 13.3 33 339
16.3 24
294 62.1 14.1 36 356
17.1 26
311 62.9 14.9 40 373
17.9 28
35 268 69.1 12.8 30 336 16.2 23 284 70.0 13.6 34 353 17.0 26 300 70.8 14.4 37 370 17.8 28
40 256 77.4 12.2 28 333 16.1 23 273 78.4 13.1 32 350 16.9 25 289 79.3 13.8 35 367 17.7 28
45 244 86.3 11.6 26 329 15.9 23 260 87.3 12.4 29 347 16.8 25 277 88.4 13.3 32 364 17.6 27
50 230 95.9 11.0 23 326 15.8 22 247 97.0 11.8 26 343 16.6 24 263 98.2 12.6 30 360 17.5 27
55 216 106 10.3 21 322
15.6 22
232 107 11.1 24 339
16.4 24
248 109 11.9 27 356
17.3 26
310
30 302 70.2 14.5 41 372
8.9
8.9
11
11
320 71.8 15.3 46 391
9.4
9.4
12
12
339 73.4 16.3 51 412
9.9
9.9
13
13
35 291 77.1 13.9 38 368
8.9
8.9
10
10
309 78.8 14.8 43 387
9.3
9.3
12
12
327 80.5 15.7 48 407
9.8
9.8
13
13
40 279 84.7 13.3 35 363
8.8
8.8
10
10
297 86.4 14.2 40 382
9.2
9.2
11
11
315 88.1 15.1 44 402
9.7
9.7
12
12
45 265 93.0 12.7 32 357
8.6
8.6
10
10
283 94.7 13.6 37 378
9.1
9.1
11
11
301 96.4 14.4 41 397
9.6
9.6
12
12
50 251 102 12.0 29 352
8.5
8.5
10
10
268 104 12.8 33 372
9.0
9.0
11
11
287
106 13.7 38 392
9.5
9.5
12
12
55 236 112 11.3 26 347
8.4
8.4
9
9
253 1
14 12.1 30 365
8.9
8.9
10
10
271 115 13.0 34 385
9.4
9.4
11
11
