Sven E-505B [13/16] E 505b

ENG

e-505B

User’s Manual

DESCRIPTION

a Charging сase LED indicator

b Headphones LED indicator

c Multifunction button

d Microphone

e Micro USB jack for battery charging

CONNECTION

First connection

•Remove both headphones from the charging

case, then put them back to the case to

activate the headphones.

•The battery in the headphones and case is

used as an integral part of the device. Before

using for the ﬁrst time, make sure that the

headphones are fully charged. If the headp-

hones are discharged, they need to be fully

charged.

Fig. 1.

Headset to a device interfacing

•It is necessary ﬁrst to interconnect the device with a signal source уto transfer signals via

Bluetooth. To pair the headphones with the device, put them to the charging case, then

get them out. Both earphones are automatically switched on and connected to each other

At the same time on the right earphone LED indicato b will alternate blue and red glow.

•It is necessary to select Bluetooth device search mode on a signal source (telephone,

notebook, smartphone, etc.). «SVEN E-505B», massage will be displayed on the screen,

which is to be connected to*.

•If connection successful, there will be a short beep signal in the headphones; the search

mode indication on the headphones is over. If no devices connected, headphones will

turned oﬀ automatically in 2 minutes.

•If you cannot connect your device or connect a headset to each other, or the sound

is played from only one earphone, you must re-enter the system to the search mode.

Put the headphones to the charging case. Take headphones out the caseand they will

automatically connect to each other. After that, pair the headphones with the device, as

described above*.

Bluetooth Technology

•Wireless data transfer via the Bluetooth protocol enables to connect wireless headphones

to compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles

as walls or other electronic devices can interfere with the signal transfer.

* You might have to enter “0000” code to connect some models of devices via Bluetooth.
