700 Series 2

706 S2

This information is intended as a guide only and reects the current specication at the time of print.

We reserve the right to make changes to the specications

www.bowers-wilkins.com

Carbon Dome, Continuum, FST

and Flowport are trademarks

of B&W Group Ltd.

Studio sound comes home

The 706 is a bookshelf/standmount speaker with the acoustic heft to

satisfy the demands of bigger rooms, thanks to its large midrange/bass

drive unit. The speaker provides real musical insight into recordings, with

details and spaciousness preserved intact.

Technical Specications

Description 2-way vented-box system

Technical features Decoupled Carbon Dome

™

tweeter

Continuum

™

cone bass/midrange

Flowport

™

Drive units 1x ø25mm (1 in) Decoupled Carbon

Dome high-frequency

1x ø165mm (6.5 in) Continuum cone

bass/midrange

Frequency range (-6dB) -6dB at 45Hz and 33kHz

Frequency Response -3dB 50Hz - 28kHz ±3dB

Sensitivity 88dB spl (2.83V

RMS, 1m)

Harmonic distortion 2nd and 3rd harmonics (90dB, 1m)

<1% 100Hz - 22kHz

<0.5% 150Hz - 20kHz

Nominal impedance 8Ω (minimum 3.7Ω)

Recommended amplier 30W - 120W into 8Ω on unclipped

power programme

Dimensions Height: 340mm (13.4 in) cabinet only

Width: 200mm (7.8 in)

Depth: 285mm (11.2 in) cabinet only

301mm (11.9 in) including grille

and terminals

Net weight 8.0kg (17.7 lb)

Finishes Cabinet: Rosenut

Gloss Black

Satin White

Grille: Black

Grey (Satin White only)
