Ariston AT 84 [3/80] Warning

The hook to be used in case the

drain hose ends at a height

below 60 cm.

If the hose drains into a tub or

sink, apply the plastic guide

and tie it to the tap.

The guide for draining into tubs

and sinks.

The hose must neverThe hose must never

The hose must never

remain immerremain immer

remain immer

sed in watersed in water

sed in water

Extensions are inadvisable. In

case of absolute need, the

extension must have the same

diameter as the original hose

and must not exceed 150 cm

in length. In case of wall

draining pipes, their efficiency

must be checked by a qualified

technician. If the dwelling is on

one of the upper floors of a

building, there may be drain

trap problems causing the

washing machine to load and

unload water continuously.

In order to avoid such an

inconvenience, special anti-

drain trap valves are available

in shops.

Connection to the waterConnection to the water

Connection to the water

mainsmains

mains

Water pressure must range

within the values indicated on

the data plate on the rear of

your washing machine.

Connect the inlet hose

(situated unassembled inside

the drum) to a cold water tap

with a 3/4 gas threaded mouth.

If the water pipes are new or

left unused, run the water until

it is clear and free of debris.

Attach the hose to the

appliance, in line with the

appropriate water pipe inlet at

the top right.ù

Connecting the drain hoseConnecting the drain hose

Connecting the drain hose

On the back of the appliance,

towards the top, you will find a

hook onto which you should

fasten the drain hose if

necessary. Insert the other end

in a wall draining duct or place

it on the edge of a sink or tub

avoiding excessive kinks and

bending.

It should be placedIt should be placed

It should be placed

at a height ranging from 60 toat a height ranging from 60 to

at a height ranging from 60 to

100 cm.100 cm.

100 cm.

In case it is necessary to fix the

end of the hose at a height

below 60 cm from the ground,

it must be fixed in the

appropriate hook placed on

the back panel as mentioned

above.

Instructions for installation and use

Installation and removal

When theWhen the

When the

appliance arrivesappliance arrives

appliance arrives

Whether new or just transported to a new house, installation is extremely

important for the correct functioning of your washing machine.

Electric connectionElectric connection

Electric connection

Before connecting the

appliance to the electric

socket, be sure that:

1) the electric socket is able

to sustain the appliance's

maximum power load

indicated on the data plate

and in compliance with the

law;

2) the supply voltage is

included within the values

indicated on the data

plate;

3) the socket is compatible

with the appliance's plug.

If not, do not use adapters,

but replace either the

socket or the plug;

4) electric household appli-

ances must be equipped

with an "earthing" system,

5) that the machine is not

placed on top of the power

supply cable once the

connection has been

made.

Warning!

Any modifications made to the

factory settings or an irregu-

lar electric connection, any

electrical, mechanical or hy-

draulic modification whatso-

ever to the appliance shall

render the guarantee invalid

and shall relieve the manufac-

turer and retailer of any and

all liability.

The feet are adjustable.

Water hose inlet to be fitted to

the top right.

Unblocking: removeUnblocking: remove

Unblocking: remove

the 4 screws!the 4 screws!

the 4 screws!

Plastic bags, polystyrene

foam, screws and other

packaging parts are not

children's toys, and are

potentially dangerous.

After removing the appliance

from its packaging, check that

it is intact. If in doubt, contact

a qualified technician

immediately.

The inside of theThe inside of the

The inside of the

machine is blocked, formachine is blocked, for

machine is blocked, for

transportation, by fourtransportation, by four

transportation, by four

screws and rubber washersscrews and rubber washers

screws and rubber washers

on the back panel.on the back panel.

on the back panel.

Before using the washing

machine,

remove theremove the

remove the

screwsscrews

screws, remove the rubber

washers with the relative

spacer (keeping all the parts)

and use the plastic tabs

provided to fill in the holes.

Warning:Warning:

Warning: should the screws

be re-used, make sure you

fasten the shorter at the top.

LevellingLevelling

Levelling

The washing machine must be

levelled appropriately in order to

guarantee its correct functioning.

o leo le

o le

vel the appliancevel the appliance

vel the appliance

the f the f

the f

eeteet

eet

must be adjustedmust be adjusted

must be adjusted; the angle of

inclination, measured according

to the worktop, must not exceed

2°. When placed on fitted carpet,

make sure the ventilation is not

obstructed within its surroundings.

Do not throw the blocking

screws and the spacers

away. In the event of a

removal, they can be used

to block the components

inside the appliance again

and so protect it during

transport.
