Measures common-
emitter gain.
hFE Transist or Test
The 2704C has all of the functionality for basic DMM applications including
some high end features you might not expect. The 2000 count LCD can display
resistance values up to 2 GΩ, capacitance to 20 uF or a transistors
common-emitter gain value up to 1000. Value-packed features make this meter a
must in every "Tool Kit
®
".
Features
■ Magnetic hanger ■ DC voltage to 1000 V
■ AC voltage to 750 V ■ Resistance to 2000 MΩ
■ Capacitance to 20 uF ■ Continuity test
■ Diode test ■ Logic test
■ hFE Transistor test
■ One-handed operation
■ Measures up to 10 A (AC & DC)
DC Volts
Ranges 200 mV, 2 V, 20 V, 200 V, 1000V
Resolution 0.1 mV, 1 mV, 10 mV, 100 mV, 1 V
Accuracy ±(0.8 % rdg + 1 dgts)
Input Impedance 10 MΩ
Overload Protection 1000 VDC or 750 VACrms*
AC Volts (50 Hz-500 Hz)
Ranges 200 mV, 2 V, 20 V, 200 V, 750V
Resolution 0.1 mV, 1 mV, 10 mV, 100 mV, 1 V
Accuracy 200 mV & 20 V ranges: ±(1.5 % rdg + 5 dgts)
200 V & 750 V ranges: ±(2.0 % rdg + 5 dgts)
Input Impedance 10 MΩ
Overload Protection 1000 VDC or 750 VACrms*
DC Cu rrent
Ranges 20 mA, 200 mA, 10 A
Resolution 10 uA, 100 uA, 10 mA
Accuracy 20 mA to 200 mA ranges: ±(1.0 % rdg + 1 dgts)
10 A range: ±(3.0 % rdg + 3 dgts)
Input Protection 0.5 A/500 V & 10 A/600 V fast blow ceramic fuses
10A Input 10 A for 60 sec max. followed by a 10 minute cooling period
*= 600 VDC/Acrms for 15 seconds on 200 mV range
AC Current (50 Hz-500 H z)
Ranges 20 mA, 200 mA, 10 A
R
esolution 10 uA, 100 uA, 10 mA
A
ccuracy 20 mA to 200 mA ranges: ±(2.0 % rdg + 5 dgts)
10 A range: ±(3.0 % rdg + 5 dgts)
Input Protection 0.5 A/500 V & 10 A/600 V fast blow ceramic fuses
1
0A Input 10 A for 60 sec max. followed by a 10 minute cooling period
Resistan ce
Ranges 200 Ω, 2 kΩ, 200 kΩ, 20 MΩ, 2000 MΩ
Resolution 0.1 Ω, 1.0 Ω, 100 Ω, 10 kΩ, 1 MΩ
A
ccuracy 200 Ω to 200 kΩ ranges: ±(1.0 % rdg + 4 dgts)
20 MΩ range: ±(2.0 % rdg + 4 dgts)
2000 MΩ range: ±(5.0 % rdg + 10 dgts)
O
pen Circuit Voltage (typical) 0.3 VDC (3.0 VDC on 200 Ω, 2000 MΩ range)
Overload Protection 500 VDC/ACrms
Capacitance
Ranges 2 nF , 20 nF, 200 nF, 2.0 uF, 20 uF
R
esolution 1 pF, 10 pF, 100 pF, 1 nF, 10 nF
A
ccuracy ±(4 % rdg + 10 dgts)
Overload Protection Discharge capacitor before connecting
Frequency
Ranges 2 kHz, 20 kHz, 200 kHz, 2 MHz, 20 MHz
Resolution 1 Hz, 10 Hz, 100 Hz, 1 kHz, 10 kHz
Accuracy ±(0.1 % rdg + 3 dgts)
Sensitivity 2.0 Vrms minimum
Minimum Pulse Width >25 ns
Duty Cycle Limits >30 % and <70 %
Overload Protection 500 VDC/AC rms
Diode Te st
Test Current 1.0 mA (typical)
Resolution 10 mV
Accuracy ±(1.5 % rdg + 3 dgts)
Open Circuit Voltage 3.0 VDC (typical)
Overload Protection 500 VDC/ACrms
Continuity
Audible Indication Less than 100 Ω
Response Time 100 ms
Overload Protection 500 VDC/ACrms
Transistor hF E
Range 0 to 1000
Base Current Approximately 10 uADC (VCE = 3.0 VDC)
Logic Te st
Threshold Logic Hi (2.8 V ±0.8 V) / Logic Lo (0.8 V ±0.5 V)
Indication 40 msec beep at logic Lo
Overload Protection 500 VDC/AC rms
General
Display 3 1/2 digit, 2000 count LCD
Polarity Automatic, positive implied, negative polarity indication
Overrange OL or -OL is displayed
Low Battery Indication Battery symbol will display when battery voltage drops below
operating levels
Measurement Rate 2.5 times per second
Operating Environment 0ºC to 50ºC at <70 % relative humidity
Storage Environment -20ºC to 60ºC at 0 to 80 % relative humidity
Accuracies Stated accuracy at 23ºC +5ºC at <75 % relative humidity
Temperature Coefficient 0.1 x (specified accuracy) per ºC. (ºC to 18ºC, 28ºC to 50ºC)
Power Single standard 9 volt battery, NEDA 1604, JIS 006P, IEC 6F22
Battery Life 150 hours typical
Dimensions 165 mm (H) x 78 mm (W) x 42.5 mm (D)
Weight Approximately 10 oz. (285 g) with battery and hanger
Specifications
2704C
model
Supplied Accessories: User manual, one set of test leads, one spare fuse, and 9V battery (installed)
Three-Year Warranty
Manual Ranging Tool Kit
®
DMM with Transistor Test
Model 2704C
