6

4. For current measurements up to 10A AC, set the function switch to the A position and insert the

red test lead banana plug into the 10A jack.

5. Press the MODE button. The measurement mode will change between AC or DC as required.

6. Remove power from the circuit under test, then open up the circuit at the point where you wish

to measure current.

7. Touch the black test probe tip to the negative side of the circuit. And touch the red test probe

tip to the positive side of the circuit.

8. Apply power to the circuit.

line cords.

1. Set the function switch to the Ω position.

2. Insert the black test lead plug into the negative (COM) socket and the red test lead plug into the

positive Ω jack.

3. Press the MODE button until “Ω” appears in the display.

4. Touch the test probe tips across the circuit or part under test. It is best to disconnect one side of

the part under test so the rest of the circuit will not interfere with the resistance reading.

5. Read the resistance in the display. The display will indicate the proper decimal point, value and

symbol.

3. Press the MODE button until “•)))” appears in the display.

4. Touch the test probe tips to the circuit or wire you wish to check.

5. If the resistance is less than 35Ω, the audible signal will sound. The display will also show the

actual resistance in ohms.

DIODE TEST

WARNING: To avoid electric shock, do not test any diode that has voltage on it.

1. Set the function switch to the position.

2. Insert the black test lead plug into the COM socket and the red test lead plug into the
