Battery life: Meter: 1000 hrs,
Insulation Test: >1000 tests
Size (HxWxD):
203 mm x 100 mm x 50 mm
Weight: 0.55 kg
Three Year Warranty
1577/1587
Insulation Multimeters
10923-eng Rev. 02
Included Accessories
C101 Rugged, utility hard case
TL224 SureGrip Silicone Test Lead Set
AC285 SureGrip Alligator Clip Set
80BK Integrated DMM Temperature Probe
(Type K)
TP165X Remote Test Probe
Ordering Information
Fluke 1577 Insulation Multimeter
Fluke 1587 Insulation Multimeter
Fluke 1587ET Advanced Electrical
Troubleshooting Kit
Fluke1587MDT Advanced Motor & Drive
Troubleshooting Kit
Two powerful tools in one
The Fluke 1587 and 1577 Insulation
Multimeters combine a digital insulation
tester with a full-featured True RMS digital
multimeter in a single compact, handheld
unit, which provides maximum versatility
for both troubleshooting and preventive
maintenance.
Whether you work on motors, generators,
cables, or switch-gear, the Fluke 1587/1577
Insulation Multimeters are ideally suited to
help you with your tasks.
1577 1587
0.1MΩ to 600MΩ 0.01MΩ to 2GΩ
500V, 1000V 50V, 100V, 250V,
500V, 1000V
+ 20%, - 0% + 20%, - 0%
1 mA nominal 1 mA nominal
Discharge time < 0.5s Discharge time < 0.5s
for C = 1µF or less for C =1µF or less
Up to 1µF load Up to 1µF load
Measurement range
Test voltages
Test voltage accuracy
Insulation test current
Auto discharge
Maximum capacitive load
Insulation Specifications
New
C25 i400 TPAK L215 TL238
Recommended Accessories
Fluke 1577
Features
Multimeter Features
True RMS Voltage and Current for accurate measurements
Autorange and manual range for easy testing.
Selectable filter for accurate voltage and frequency measurements on motor
drives
Min Max Recording, Diode test, temperature, capacitance & frequency
measurement for maximum flexibility.
Insulation features
User selectable test voltages for many applications
Special remote control probe for easy and safe measurements
Auto-discharge of capacitive voltage for added user protection
Live circuit detection prevents insulation test if voltage > 30V is detected for
added user protection
General features
Auto Power off to save batteries
Large display with backlight
Input Alert to warn for incorrect connections
Continuity
1577 1587
●●
●●
●
●
●●
●●
●●
●●
●●
●●
●●
●●
Functions Maximum Max. resolution
Voltage DC 1000V 1 mV
Voltage AC 1000V 0.1mV
Current DC 400mA 0.01mA
Current AC 400mA 0.01mA
Resistance 50.0MΩ 0.1Ω
Capacitance 9999µF 1 nF
Frequency 99.99kHz 0.01 Hz
Temperature -40°C to +537°C 0.1°C
1577 1587
± (0.2% + 2) ± (0.09% + 2)
± (2% +3) ± (2% + 3)
±(1.0% + 2) ± (0.2% + 2)
± (2% + 2) ± (1.5% + 2)
±(1.2% + 2) ± (0.9% + 2)
-±(1.2% + 2)
-±(0.1% + 1)
-±(1% + 10)
Fluke 1587
Multimeter Specifications
