2 Fluke Corporation Fluke 83V and 87V detailed specifications
Fluke 83V and 87V Detailed Specifications cont.
DC voltage, resistance, and conductance function
specifications
Accuracy
Function Range Resolution Fluke 83V Fluke 87V
V 6.000 V 0.001 V ± (0.1 % + 1) ± (0.05 % + 1)
60.00 V 0.01 V ± (0.1 % + 1) ± (0.05 % + 1)
600.0 V 0.1 V ± (0.1 % + 1) ± (0.05 % + 1)
1000 V 1 V ± (0.1 % + 1) ± (0.05 % + 1)
mV
600.0 mV 0.1 mV ± (0.3 % + 1) ± (0.1 % + 1)
Ω 600.0 Ω 0.1 Ω ± (0.4 % + 2)
1
± (0.2 % + 2)
1
6.000 kΩ 0.001 kΩ ± (0.4 % + 1) ± (0.2 % + 1)
60.00 kΩ 0.01 kΩ ± (0.4 % + 1) ± (0.2 % + 1)
600.0 kΩ 0.1 kΩ ± (0.7 % + 1) ± (0.6 % + 1)
6.000 MΩ 0.001 MΩ ± (0.7 % + 1) ± (0.6 % + 1)
50.00 MΩ 0.01 MΩ ±(1.0 % + 3)
2
±(1.0 % + 3)
2
60.00 nS 0.01 nS ± (1.0 % + 10)
1
±(1.0 % + 10)
1
1
When using the REL ∆ function to compensate for offsets
2
Add 0.5 % of reading when measuring above 30 MΩ in the 50 MΩ range and
20 counts below 33 nS in the 60 nS range
nS
Temperature specifications
(87V only)
Temperature Resolution Accuracy
1, 2
-200 °C to +1090 °C 0.1 °C 1 % + 10
-328 °F to +1994 °F 0.1 °F 1 % + 18
1
Does not include error of the thermocouple probe.
2
Accuracy specification assumes ambient temperature stable to ± 1 °C.
For ambient temperature changes of ± 5 °C, rated accuracy applies
after 1 hour.
Current function specifications
Accuracy
Burden Voltage
Function Range Resolution Model 83
1
Model 87
2, 3
(typical)
mA 60.00 mA 0.01 mA ± (1.2 % + 2)
5
±(1.0 % + 2) 1.8 mV/mA
A~ 400.0 mA
6
0.1 mA ± (1.2 % + 2)
5
±(1.0 % + 2) 1.8 mV/mA
6.000 A 0.001 A ± (1.2 % + 2)
5
±(1.0 % + 2) 0.03 V/A
(45 Hz to 2 kHz) 10.00 A
4
0.01 A ± (1.2 % + 2)
5
±(1.0 % + 2) 0.03 V/A
mA 60.00 mA 0.01 mA ± (0.4 % + 4) ± (0.2 % + 4) 1.8 mV/mA
A 400.0 mA
6
0.1 mA ± (0.4 % + 2) ± (0.2 % + 2) 1.8 mV/mA
6.000 A 0.001 A ± (0.4 % + 4) ± (0.2 % + 4) 0.03 V/A
10.00 A
4
0.01 A ± (0.4 % + 2) ± (0.2 % + 2) 0.03 V/A
µA~ 600.0 µA 0.1 µA ± (1.2 % + 2)
5
±(1.0 % + 2) 100 µV/µA
6000 µA 1 µA ± (1.2 % + 2)
5
±(1.0 % + 2) 100 µV/µA
(45 Hz to 2 kHz)
µA 600.0 µA 0.1 µA ± (0.4 % + 4) ± (0.2 % + 4) 100 µV/µA
6000 µA 1 µA ± (0.4 % + 2) ± (0.2 % + 2) 100 µV/µA
1
AC conversion for Model 83 is ac coupled and calibrated to the rms value of a sine wave input.
2
AC conversions for Model 87 are ac coupled, true rms responding, and valid from 3 % to 100 % of range.
3
Model 87 is a true rms responding meter. When the input leads are shorted together in the ac functions, the Meter may display a residual reading between 1 and
30 counts. A 30 count residual reading will cause only a 2 digit change for readings over 3 % of range. Using REL to offset this reading may produce a much larger
constant error in later measurements.
4
10 A continuous up to 35 °C; < 20 minutes on, 5 minutes off at 35 °C to 55 °C. 20 A for 30 seconds maximum; > 10 A unspecified.
5
Below a reading of 200 counts, add 10 counts.
6
400 mA continuous; 600 mA for 18 hours maximum.
Capacitance and diode function specifications
Function Range Resolution Accuracy
10.00 nF 0.01 nF ± (1 % + 2)
1
100.0 nF 0. 1 nF ± (1 % + 2)
1
1.000 µF 0.001 µF ± (1 % + 2)
10.00 µF 0.01 µF ± (1 % + 2)
100.0 µF 0.1 µF ± (1 % + 2)
9999 µF 1 µF ± (1 % + 2)
3.000 V 0.001 V ± (2 % + 1)
1
With a film capacitor or better, using Relative mode to zero residual.
