Safety Information

To avoid possible electric shock or personal injury:

• Never apply more than 30V between any two jacks, or between any jack and earth ground.

• Make sure the battery door is closed and latched before you operate the calibrator.

• Remove test leads from the calibrator before you open the battery door.

• Do not operate calibrator if it is damaged.

• Do not operate the calibrator around explosive gas, vapor, or dust.

To avoid possible damage the calibrator:

• Make sure choose the right jack and rang, before use the calibrator to measurement or calibrator.

• Take away the calibrator from the used circumstance, before operate the calibrator or after close

the calibrator.

Introduction

RTD Process Calibrator is exactitude measurement and source instrument, it can be use to calibrate

the RTD

transmitter (include most impulse transmitter).

RTD Process Calibrator can measure or simulate 7 difference types of RTD (

C or

F) and measure

or simulate the Resistance. But it could not use to measurement or source at a same time.

The accessories: 2 pair of test lead and alligator clip, 6 *AAA 1.5V battery, user’s manual.

If the Calibrator is broken or short of some accessories, please contact the supplier.

The following table has showed the technical parameter and function of the Calibrator.

Specification

All the specification will under 1 year calibration cycle and temperature between 18~28

except addition explain.

Measure (input)/Simulate (output) Resistance specification.

Range Measure accuracy

4W ± Ω

Simulate accuracy

± Ω

Admie excitation

0,00 Ω ~400,00 Ω

0,1

0,15 0,1 ~ 0,5

0,1 0,5 ~ 3,0

400,0 Ω ~ 1500,0 Ω 0,5 0,5 0,05 ~ 0,8

1500,0 Ω ~ 3200,0 Ω

0,05 ~ 0,4

RTD Resistance Temperature Detector
