Safety Information

To avoid possible electric shock or personal injury:

Never apply more than 30V between any two jacks, or between any jack and earth ground.

Make sure the battery door is closed and latched before you operate the calibrator.

Remove test leads from the calibrator before you open the battery door.

Do not operate calibrator if it is damaged.

Do not operate the calibrator around explosive gas, vapor, or dust.

To avoid possible damage to the calibrator:

Make sure you choose the right jack and range before you use the calibrator to measurement or

calibrator.

Take away the calibrator from the used circumstance, before operate the calibrator or after close

the calibrator.

Introduction

Thermocouple Process Calibrator is a exactitude measurement and source handhold instrument,

it can be used to calibrate the Thermocouple instrument.

Thermocouple Process Calibrator can measure or simulate 8 types of difference Thermocouple

(°C or°F), and measure or simulate the millivolt. But it cannot be used for measurement or source

at the same time.

The accessories: 2 pcs Thermocouple plugs (no wire), 6 * AAA 1.5V battery, user’s manual.

If the Calibrator is broken or short of some accessories, please contact the supplier.

The following table has showed the technical parameter and function of the Calibrator.

Specification

All the specification will under 1 year calibration cycle and temperature between 18~28°C,

except addition explain.

Measure (input)/Simulate (output) Millivolt specification
