Safety Information

To avoid possible electric shock or personal injury:

• Never apply more than 30V between any two jacks, or between any jack

and earth ground.

• Make sure the battery door is closed and latched before you operate the calibrator.

• Remove test leads from the calibrator before you open the battery door.

• Do not operate calibrator if it is damaged.

• Do not operate the calibrator around explosive gas, vapor or dust.

To avoid possible damage the calibrator:

• Make sure choose the right jack and rang, before use the calibrator to measurement or calibrator.

• Take away the calibrator from the used circumstance, before operate the calibrator or after

closed calibrator.

Introduction

Volt/mA Calibrator is a source and measurement tool. This Calibrator is use to measure or output

0 to 24 mA DC current loop, and 0 to 15 DC voltage. But the calibrator cannot be used to

measurement and source simultaneously.

Volt/mA Calibrator include this accessories: Holster, a pair of Test Leads, AAA*6 battery, and this

manual.

If the calibrator is broken or short of some accessories, please contact the supplier. Please contact

the distributor about other accessory’s information.

The following table has showed the technical parameter and function of the Calibrator.

Measurement and output voltage parameter

Function Range Resolution

DC V mV Input Auto range 0 ~ 110 mV 0,01 mV

0 ~ 15 V 0,001 V

DC V mV Output manual range 0 ~ 100 mV 0,01 mV

0 ~ 15 V 0,001 V

Loop Power Output 24 V DC N/A

Measurement and output mA parameter

Function Range Resolution

DC mA Input 0 ~ 24 mA 0,001 mA

DC mA Output 0 ~ 24 mA 0,001 mA
