AXIOMET AX-3020L [3/4] Operating instructions

Figure 1

1. Voltage indication

2. Curretn indication

3. +S outupt port

4. –S output port

5. – Output port

6. + Output port

7. – Output terminal

8. + Output terminal

9. Power switch

10. Output light

11. Output switch

12. Voltage adjustment knob

13. Current adjustment pot

14. Chassis ground

3. Operating instructions

1. Press the power ON/OFF button to turn power on.

2. Adjust the voltage knob to set the desired voltage. (Voltage level is shown on the digital display).

3. Adjust the current level pot with a small regular screwdriver to set the(maximum) desired current

level. (The current of the power supply is must to be the maximum at the factory).

4. Connecting a load to the output terminals and pressing the output switch will illuminate the output

indicator light and the current output can be read on the digital display.
