Chapter 1. Introduction

This manual contains information and warnings, which must be followed to ensure safe operation

and retain the DC power supply in safe condition.

WARNING

READ “ SAFETY INFORMATION ” BEFORE USING, INSTALLING

OR MAINTENANCE THE INSTRUMENT.

The DC power supply series are a bench multiple output power supplies. Their output voltage and

output current can be all adjusted continuously by turn the regulator on panel. Constant voltage

and current can be transformed automatically as well. They are a kind of high-steady multiple

output DC power supply.

The DC power supply series have been designed according to IEC1010–1 concerning safety

requirements and comply with.

About the output voltage and current for the DC power supply series:

1. There are double output voltage and double output current and its output voltage and current

can be adjusted continuously for the DC power supply.

2. There are triple outputs, one of output is double output voltage and double output current and

its output voltage and current can be adjusted continuously, besides with a fixed 5V3A output for

the DC power supply.

About the display of output voltage and current for the DC power supply series:

There are four display types for the DC power supply series monitoring output voltage and current.

They are LCD, LED, two pointer meters and four pointer meters.

1. LCD display:double output voltage and current can be all display simultaneously.

2. LED display:display output voltage or current respectively by transforming switch on panel for

each unit (master or slave unit).

3. Two pointer meters display:display output voltage or current respectively by transforming

switch on panel for each unit (master or slave unit).

4. Four pointer meters display:double output voltage and current can be display simultaneously.

One of them is equipped to the DC power supply. See figure 4-3 to figure 4-6.

NOTE: There is no display for fixed 5V3A output.
