Uni-T UT56 Расширенная инструкция онлайн [3/17] 528140
![Uni-T UT56 Расширенная инструкция онлайн [3/17] 528140](/views2/1665312/page3/bg3.png)
Low Battery Earth Ground
Safety Rules
Double Insulated
AC
Diode
Dangerous Voltages
DC
Buzzer
Fuse
l Replace the battery as soon as the battery
indicator" "appears. With a low battery,
the Meter might produce false readings
that can lead to electric shock and personal
injury.
l Turn off the Meter once finished measuring.
Fetch out the battery, when the meter will
not be used for long period.
l Do not operate the Meter under adverse
environmental condition including high
temperature and especially humid area as
the Meter's function may be effected after
moisturizing.
l To avoid damages and dangerous, do not
change the circuit on your own.
l Periodically wipe the cabinet with a damp
cloth and mid detergent. Do not use
abrasives or solvents.
l Dispose the used battery proper.
l International Electrical Symbols.
Model UT56: OPERATING MANUAL
3
Содержание
- B 3 direct current current dc current 6
- B 4 alternate current current ac current 6
- Overload protection below 200ma with 0 a 250v fused no fuse protection on 20a max current input 20a above 10a for 15 seconds maximum measuring voltage drop full ranges are 200mv 6
- Overload protection below 200ma with0 a 250v fused no fuse protection on 20a max current input 20a above 10a for 15seconds maximum measuring voltage drop full ranges are 200mv display average value rms of sine wave 6
- B 5 resistance 7
- B 6 capacitance 7
- Overload protection all ranges are 250vdc or ac rms caution 1 at 200 7
- Range short the test lead first to display the resistance value of the test leads deduct that resistance value from the measured reading to obtain the being measured object correct value 7
- Range test lead is short circuit the lcd display 1000 digits deduct the 1000 digits from the measured reading during measuring 2 at 20 7
- Testing signals about 400hz 40mvrms 7
- 7 frequency 8
- 8 diode and continuity beeper 8
- B 9 transistor hfe test 8
- Input sensitivity 200mvrms max input scope 30vrms overload protection 250vrms 8
- Khz 1hz 1 5 8
- Overload protection 250v dc or ac rms 8
