2-7 Frequency
Range Resolution Accuracy
20kH
z
1H
z
(1.5% +5)
Input sensitivity: <200mVrms, Max. input
scope 30Vrms.
Overload protection: 250Vrms.
2-8 Diode and Continuity Beeper
Overload protection: 250V DC or AC RMS.
B-9 Transistor hFE test
Range Remark Measuring Condition
Display Diode
Forward Voltage
Value, unit is "V"
Forward DC Current abt
1mA, Backward DC
Voltage abt3.0V
Beeper sounds when
Resistance < 50Ω.
Display the nearest
value, unit is "kΩ"
Voltage at open Circuit
abt 3.0V
Range Remark Measuring Condition
hFE
Can Measure NPN
and PNP type
Transistor, Display
ranges: 0-1000 β
Basic polarity current abt
10µA,Vce abt 3.0V
Model UT56: OPERATING MANUAL
