Uni-T UT61D [14/69] Display symbols

Display Symbols

Meaning

Data hold is active.

Sleep Mode indicator

Indicates negative reading.

Indicator for AC measurement

Indicator for DC measurement

The Meter is in the auto range mode in which the Meter automatically

selects the range with the best resolution.

Indicator for manual ranging mode.

The input value is too large for the selected range.

Transistor testing indicator

Test of diode

The continuity buzzer is on.

Maximum and Minimum reading.

Data output is in progress

The battery is low.

Warning: To avoid false readings, which could lead to

possible electric shock or personal injury, replace the battery

as soon as the battery indicator appears.

Sensor test is in progress

Symbol

Model UT61A/61B/61C/61D/61E: OPERATING MANUAL
