Warning

Before connecting the Meter to the return circuit to be tested, cut off the current

of the return circuit.

If the fuse burns out during measurement, the Meter may be damaged or the

operator himself may be hurt.

Use proper terminals, function, and range for the measurement.

When the testing leads are connected to the current terminals, do not parallel

them across any circuit.

To measure current, do the following:

1. Insert the red test lead into the mA or A input terminal and the black test lead

into the COM terminal.

2. Set the rotary switch to A, mA, or A.

3. The Meter defaults to DC current measurement mode. To toggle between DC

and AC current measurement function, press BLUE button.

4. Connect the test lead in serial to the return circuit to be tested. The measured

value shows on the display.

Model UT61A/61B/61C/61D/61E: OPERATING MANUAL
