Model UT71A/B: OPERATING MANUAL

Table 2-4. Display Features

No. Symbol Meaning

nF,µF,

LOW

HIGH

AUTO

SEND

Farad. The unit of capacitance

nF: Nanofarad. 1x10

-9

or 0.000000001 farads.

µF:Microfarad.1x10

-6

or 0.000001 farads.

mF: Millifarad. 1x10

-3

or 0.001 farads.

Automatic power off feature is on

Continuity test

Data store is on

Data recall is on

The relative mode is on to display the present value minus the stored value.

The indicator for the lowest setup limit.

The indicator for the highest setup limit.

The Meter is in the auto range mode in which the Meter automatically selects the

range with the best resolution.

Data output is in progress

(UT71B only)

STO

RCL

(UT71B only)
