Model UT71A/B: OPERATING MANUAL

Safety Information

This Meter complies with the standards IEC61010 safety

measurement requirement: in pollution degree 2,

overvoltage category (CAT. III 1000V, CAT.IV 600V)

and double insulation.

CAT. III: Distribution level, fixed installation, with smaller

transient overvoltage than CAT. IV

CAT.IV: Primary supply level, overhead lines, cable

systems etc.

Use the Meter only as specified in this operating manual,

otherwise the protection provided by the Meter may be

impaired.

In this manual, a Warning identifies conditions and

actions that may pose hazards to the user, or may

damage the Meter or the equipment under test.

A Note identifies the information that user should pay

attention to.

International electrical symbols used on the Meter and

in this Operating Manual are explained on page 9.

Rules For Safe Operation

Warning

To avoid possible electric shock or personal injury,

and to avoid possible damage to the Meter or to the

equipment under test, adhere to the following rules:

Before using the Meter inspect the case. Do not

use the Meter if it is damaged or the case (or part

of the case) is removed. Look for cracks or missing

plastic. Pay attention to the insulation around the

connectors.

Inspect the test leads for damaged insulation or

exposed metal. Check the test leads for continuity.

Replace damaged test leads with identical model

number or electrical specifications before using the

Meter.

Do not apply more than the rated voltage, as marked

on the Meter, between the terminals or between any

terminal and grounding.

The rotary switch should be placed in the right

position and no any changeover of range shall be

made during measurement is conducted to prevent

damage of the Meter.
