The B&K Precision model 5492B is a versatile
5½-digit, 120,000-count bench multimeter
suitable for applications in education, service
repair, and manufacturing. The instrument
enhances your productivity with built-in math
functions and USB connectivity. Rel, Max/Min,
dBm, dB, %, and Hold functions provide
educators with a convenient tool to teach basic
math concepts. Additionally, the 5492B offers
powerful features not commonly found in other
5½- digit DMMs such as advanced triggering,
buffer storage operation, and a GPIB interface
option.
True RMS Bench Multimeter
5492B
True RMS Bench Multimeter
Increase Productivity with PC Connectivity
Features & benefits
Data Sheet
www.bkprecision.com
■ 5½-digit, 120,000-count display resolution
■ 0.01% basic VDC accuracy
■ Advanced triggering options such as external,
bus and event trigger
■ Two and four-wire resistance measurement up
to 120 MΩ
■ AC voltage and AC current measurement over
wide frequency range (ACV 100 kHz/ACI 10
kHz)
■ AC (RMS) and DC current measurements up
to 12 A
■ Limit mode for Pass/Fail testing
■ Save/recall up to 10 instrument settings
■ Built-in math functions: Rel, Max/Min, dBm,
dB, %, Hold, Limit Test
■ CATI (1000 V)/CATII (300 V) protection
■ USB (Virtual Com) and RS232 interface
■ SCPI compatible
Technical data subject to change
© B&K Precision Corp. 2017
The 5492B measures volts and amps with great
accuracy and stability, with basic VDC accuracy
of 0.01%. The meter is also capable of measur-
ing frequency, period, resistance, continuity, and
performing diode tests. Readings can be taken at
a maximum rate of 57 readings/sec and stored
to an internal 512-byte buffer for post
acquisition statistical analysis.
The 5492B was designed for cost-conscious
users requiring an accurate meter with a broad
range of features offered at a value price.
The 5492B is programmable via USB, RS232,
and GPIB (5492BGPIB only) interface using
industry standard SCPI commands. Users can
remotely control and configure the instrument
from a PC and retrieve measurement results for
further analysis. The multimeter can also be
remotely controlled using application software
(via USB & RS232), which supports front panel
emulation and data logging of measurement
results.
