Press U or V to scroll between F8808A and F45. The presently selected mode will
appear bright in the display, while the other is dim.
Press R to set the mode and reset the Meter.
Illuminating All Display Segments
To illuminate all display segments, start with the Meter display off. Next, press and hold
S then press P to turn on the Meter. Release the buttons when the display
illuminates. To return to normal measurement mode, press S.
