6 Fluke Corporation 8845A and 8846A
Additional Ohms Errors
Digits NPLC Additional NPLC Noise Error
6½ 100 0 % of range
6½ 10 0 % of range
5½ 1 0.001 % of range
5½ 0.2 0.003 % of range ±7 mΩ
4½ 0.02 0.017 % of range ±15 mΩ
DC Current
Input Protection............................................................Tool-accessible 11 A/1000 V and 440 mA/1000 V fuses, limits of 400 mA continuous
550 mA for 2 minutes on, 1 minute off.
Common Mode Rejection............................................140 dB at 50 or 60 Hz ±0.1 % (1 kΩ unbalance)
Normal Mode Rejection ..............................................60 dB for NPLC of 1 or greater with analog filter off and power line frequency ±0.1 %
100 dB for NPLC of 1 or greater with analog filter on and power line frequency ±0.1 %
Analog Filter..................................................................When using the analog filter, specifications are relative to within one hour of using the
ZERO function for that range and NPLC setting.
Input Characteristics
Resolution
Range Resolution
4½ Digits 5½ Digits 6½ Digits
Shunt Resistance
(Ohms)
Burden Voltage
100 µA 100.0000 µA 10 nA 1 nA 100 pA 100 Ω <0.015 V
1 mA 1.000000 mA 100 nA 10 nA 1 nA 100 Ω <0.15 V
10 mA 10.00000 mA 1 μA 100 nA 10 nA 1 Ω <0.025 V
100 mA 100.0000 mA 10 µA 1 μA 100 nA 1 Ω <0.25 V
400 mA
[3]
400.000 mA 100 µA 10 µA 1 μA 1 Ω <0.50 V
1 A
[2]
1.000000 A 100 µA 10 µA 1 μA 0.01 Ω <0.05 V
3 A
[1]
3.00000A 1 mA 100 µA 10 µA 0.01 Ω <0.15 V
10 A 10.00000 A 1 mA 100 µA 10 µA 0.01 Ω <0.5 V
[1] Part of 10 A range.
[2] Available on the front panel terminal only.
[3] 400 mA available in software version 2.0 or greater only. 400 mA continuously; 550 mA for 2 minutes on, 1 minute off.
Accuracy (8846A)
Accuracy is given as ± (% measurement + % of range)
Range
24 Hour
(23 ±1 °C)
90 Days
(23 ±5 °C)
1 Year
(23 ±5 °C)
Temperature
Coefficient/ °C
Outside 18 to 28 °C
100 µA 0.01 + 0.02 0.04 + 0.025 0.05 + 0.025 0.002 + 0.003
1 mA 0.007 + 0.005 0.030 + 0.005 0.05 + 0.005 0.002 + 0.0005
10 mA 0.007 + 0.02 0.03 + 0.02 0.05 + 0.02 0.002 + 0.002
100 mA 0.01 + 0.004 0.03 + 0.005 0.05 + 0.005 0.002 + 0.0005
400 mA
[3]
0.03 + 0.004 0.04 + 0.005 0.05 + 0.005 0.005 + 0.0005
1 A
[2]
0.03 + 0.02 0.04 + 0.02 0.05 + 0.02 0.005 + 0.001
3 A
[1][2]
0.05 + 0.02 0.08 + 0.02 0.1 + 0.02 0.005 + 0.002
10 A
[2]
0.1 + 0.008 0.12 + 0.008 0.15 + 0.008 0.005 + 0.0008
[1] Part of 10 A range
[2] Available at front panel connectors only
[3] 400 mA available in software version 2.0 or greater only. 400 mA continuously; 550 mA for 2 minutes on,
1 minute off.
