1
Introduction
XWWarning
Read “Safety Information” before using this Meter.
The descriptions and instructions in this manual apply to the
model 289 and model 287 True-rms Digital Multimeters
(hereafter referred to as the Meter). The model 289 appears in all
illustrations.
Contacting Fluke
To contact Fluke, call:
USA: 1-888-993-5853
Canada : 1-800-363-5853
Europe : +31 402-675-200
Japan: +81-3-3434-0181
Singapore : +65-738-5655
Anywhere in the world: +1-425-446-5500
Visit Fluke's web site at: www.fluke.com
Register your Meter at: http://register.fluke.com
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals
.
Safety Information
The Meter complies with:
• ANSI/ISA 82.02.01 (61010-1) 2004
• UL 61010B (2003)
• CAN/CSA-C22.2 No. 61010-1-04
• IEC/EN 61010-1 2
nd
Edition Pollution Degree 2
• EMC EN 61326-1
• Measurement Category III, 1000V, Pollution Degree 2
• Measurement Category IV, 600 V, Pollution Degree 2
In this manual, a Warning identifies hazardous conditions and
actions that could cause bodily harm or death. A Caution
identifies conditions and actions that could damage the Meter,
the equipment under test, or cause permanent loss of data.
XWWarning
To avoid possible electric shock or personal
injury, follow these guidelines:
• Use this Meter only as specified in this
manual or the protection provided by the
Meter might be impaired.
• Do not use the Meter if it is damaged. Before
you use the Meter, inspect the case. Look for
cracks or missing plastic. Pay particular
attention to the insulation surrounding the
connectors.
