For detailed specifications go to www.Amprobe.eu

Specialty Clamp Multimeters

Custom designed to make HVAC/R Service, Electrical, and Industrial

maintenance tasks faster and easier.

AC75B Three tools in one: 600 A AC clamp meter,

multimeter and thermometer

Automatic AC clamp meter with two unique features: AutoTect™ and automatic

backlight. The AutoTect feature senses what type of measurement is being made across

the test leads. The automatic bright blue backlight has a sensor that recognizes when the

ambient light becomes dim and turns itself on.

B AutoTect™ Function – automatically

selects AC volts, DC volts or resistance

B Automatic bright blue backlight

B Easy one-button control

B AC current to 600 A

B AC volts to 750 V

B DC volts to 1000 V

B Resistance and Continuity Beeper

B Data Hold

B Jaw opening 32 mm

B Safety acc. EN 61010, CAT III/600 V,

CAT II/1000 V

AC71B Automatic 600 A AC Clamp Multimeter

AC68C AC/DC TRMS 600A Clamp Meter

B Measures non-linear load current

B True RMS reading

B Autoranging for frequency

measurement

B Data Hold button, holds the display

reading for all functions and ranges

B Measures freqency through jaws

or test leads

B Low battery indicator

B DC current (Zero adjustment button)

B Peak Hold, converts and displays

the peak value for AC volts and

amps readings

B Jaw opening 40 mm

B Carrying case included

B Safety acc. EN 61010, CAT III/300 V,

CAT II/600 V

Leakage Clamp Meters

The compact size of these two meters make them ideal for taking general measurements on small

conductors. Their excellent accuracy and resolution offer exceptional performance.

B Measures AC and DC current into the

low milliamp range up to 40A

B Auto Zero DC for correct measurement every time

B High 1 mA current resolution for quick circuit

comparison on sensor and control circuits

B Auto power off function

B Jaw opening 20 mm

B Safety acc. EN 61010, CAT III/300 V

LH41A Low Current AC/DC Clamp Meter

FEATURES AC75B AC71B AC68C AC50A LH41A

ACD-16

PRO

ACD-16

TRMS-PRO

TRMS

N/A Yes N/A Yes

AC Voltage

4.000, 40.00, 400.0,

750 V

1.3 V to 750.0 V 600 V 400.0 V N/A 600.0V

DC Voltage

4.000, 40.00, 400.0,

1000 V

1.8 V to 1000.0 V

-0.6 V to -1000.0 V 400.0, 600 V

N/A 600.0V

AC Current

400.0, 600 A

40.00m, 400.0m,

4.000, 40.00, 60.0 A

N/A 40.0 / 400.0 / 1000 A

DC Current

400.0, 4000 A N/A 400.0, 600 A N/A 4.000, 40.00 A N/A

Resistance

400, 4 k, 0 k, 400 k,

4 M, 40 MΩ

100.0 Ω

4.000 kΩ

400.0 Ω N/A 999.9Ω

Diode Test

N/A 0.001 V N/A

Continuity

Yes N/A

Capacitance

4 n, 40 n, 400 n, 4 Ω,

40 Ω, 400 Ω, 4 mF

N/A

Frequency

N/A 4.000 kHz, 20.00 kHz N/A 5.00Hz to 500.0Hz

Temperature

0 °C, 400 °C N/A N/A -50 °C to 300 °C

Peak Hold

N/A N/A Yes N/A

B 600A AC Current

B Digital thermometer 400 °C, Type K probe

included

B AC/DC 750 V/1000 V

B 40 MΩ Resistance

B Low DC µA Amps for ﬂame rod

detector testing

B Capacitance to 4000 µF for motor

run/start testing

B Continuity beeper

B 4000-count large digit display

B Auto power off

B Full overload protection

B Jaw opening 35 mm

B Safety acc. EN 61010, CAT III/600 V,

CAT II/1000 V

CLAMP METERS

Recording Clamp Multimeters

Need the perfect tool to troubleshoot a system? These clamp-ons provide a full range of

measurements, enhanced with data logging capabilities, to catch what the eye can’t see.

Double the efficiency, with an optional PC interface kit (RS-232 KIT2).

B TRMS & Backlight Screen

(ACD-16 TRMS Pro only)

B Measurements: AC/DC Voltage up to

600V, AC Current up to 1000A,

Resistance, Frequency and Temperature

B Data-logging 5400 points

B Audible continuity

B Auto power off

B Automatic polarity

B Data hold

B “Third hand” - test probe holder

B Jaw opening 45 mm

B Safety acc. EN 61010, CAT III/600 V

ACD-16 PRO, ACD-16 TRMS-PRO

1000A AC Data-Logging Clamp Multimeters

B AC current measurement to 60 A

B Leakage current measurements

with resolution of 0.01 mA

B AC voltage to 400 V

B Resistance measurement

and continuity beeper

B Min/Max control to see

largest and smallest values

B Jaw opening 30 mm

B Safety acc. EN 61010, CAT III/300 V

AC50A Leakage AC Current Clamp Multimeter
