CHAUVIN ARNOUX CA-F205 [8/50] Presentation

1 PRESENTATION

The F205 is a professional electrical measuring instrument that combines the

following functions:

 Current measurement;

 Measurement of inrush current / overcurrent (True-Inrush);

 Voltage measurement;

 Frequency measurement;

 Measurement of level of harmonics (THD)

 Continuity test with buzzer;

 Resistance measurement;

 Diode test;

 Power measurements (W, VA, var and PF);

 Indication of the order of the phases.

Item Designation See §

Jaws with centring marks

(see connection principles)

3.5 to

3.14

2 Physical guard -

3 Switch 1.1

4 Function keys 2

5 Display unit 1.3

6 Terminals 1.4

7 Trigger -

Figure 1 : the F205 clamp multimeter
