The Adapter function helps
to extend the instrument’s
possibilities through
the use of measurement
probes (luxmeter, Infrared
temperature sensor,
tachometer, etc.) with voltage
output (AC or DC).
A cleverly-designed system
allows users to read the
quantity measured directly.
This 11-model range of clamp multimeters meets all your needs in the eld.
1/ MEASUREMENT RANGE
3 series identiable by their rst digit for 3 measurement ranges
• The F200 Series for currents up to 600 A
AC
/ 900 A
DC
• The F400 Series for average currents up to 1,000 A
AC
/ 1,500 A
DC
• The F600 Series for high currents up to 2,000 A
AC
/ 3,000 A
DC
All the models also innovate by proposing as standard features:
• AC and DC voltage measurement up to 1,000 V
• Resistance and audible continuity
• Min / Max analysis
•
overcurrent measurement
2/ TYPE CURRENT & FUNCTIONS
Each series comprises 3 or 4 models.
The last digit in each clamp’s name corresponds to different applications and levels of analysis.
So the F201, F401 and F601 clamps, for example, offer the same functions but with different
measurement ranges.
Voltage up to 1,000 V Resistance, audible continuity
F201 / F401 / F601
AC Applications
All the basics for
mains-powered
installations
and equipment.
F203 / F403 / F603
“AC or DC”
Applications
DC current
Temperature
Adapter function
∆REL
Phase rotation
To determine the phase order,
a “2-wire” microprocessor-
based measurement system
avoids the constraints and
faults linked to instruments
equipped with resistive or
capacitive technologies when
using protective accessories
(gloves, mats, etc.) or isolating
transformers.
F205 / F405 / F605
“Mixed AC+DC”
Applications + Testing
& Maintenance
Power values
THD
∆REL
Min/Max/Peak
Phase rotation
Ripple
The ripple is a parameter
that enables you to assess the
quality of the smoothing on
currents which are rectied
and then smoothed. The
lower the ripple factor, the
greater the efciency of the
smoothing.
If switching power supplies
are involved, the voltage
supplied includes residual
ripple, particularly at high
frequency.
This ripple is harmful for
electronic equipment, so it
should be kept to a minimum.
F407 / F607
“Mixed AC+DC”
Applications +
Analysis & Surveys
Power values
Harmonics
Ripple
Recording
PC software
F200
600 A
AC
/ 900 A
DC
F400
1,000 A
AC
/ 1,500 A
DC
F600
2,000 A
AC
/ 3,000 A
DC
Choose Your Clamp Multimeter Choose Your Clamp Multimeter
