The PAC 10 and PAC 20 Series clamps offer an ergonomic design and high-performance technical

specifications making them extraordinarily simple to use. The PAC models can be used to measure direct or

alternating, sinusoidal or distorted currents with or without a DC component.

The result of considerable study in the field, the PAC Series is available with 2 specific jaw shapes. Hooked up

to a multimeter, logger, oscilloscope, etc., the PAC clamp simplifies measurement of all currents, without any

risk and without shutting down the installation.

h As soon as a PAC clamp is powered up, a LED

indicates that it is in operation, that an external

power pack is connected and that the standby

mode is activated (green colour) or deactivated

(orange colour).

h Before any current measurements, you must adjust

the DC Zero which can be done instantaneously by

simply pressing with your thumb.

h If the current measured is too high, a red LED flashes.

y The PAC 15 is the essential accessory for multimeters. Simple

and effective with its single 1 mV/A sensitivity and "direct reading",

the PAC 15 clamp measures currents up to 400 A

ac and 600 Adc,

directly on an installation in operation (no opening of circuit).

y The PAC 16, the flagship model in the PAC 10 Series, offers dual

sensitivity alongside the functions present on all the models such

as automatic Zero DC adjustment, deactivatable automatic

power-off and possibility of using a standard external power

supply.

y This clamp is also available in a version for oscilloscopes: PAC17.

y The PAC 26 is designed for measuring relatively high currents, up to 1,000 Aac and 1,400 Adc.

Conductors carrying such high currents are usually large-diameter cables or busbars, in a protected and relatively well-ventilated

environment. In particular, this is the case for transformer stations and electrical distribution in industry, etc. To optimize measurement, the

clamp opening is centred to allow the jaws to open widely.

y 2 other versions of this clamp are available: the PAC 27, a bi-calibre isolated current sensor for oscilloscopes, and the PAC 25, a single-

calibre clamp with "direct reading" for multimeters.

Jaws designed for easy handling

The off-centre opening of these clamps

means that their mobile jaws can

be used to "scoop up" cables and

wires as if it were a shovel.

This "wire" can then be hooked onto it

thanks to the beak shape of the fixed

jaw. This means you can pull slightly on

a wire to disengage it a little.

PAC 15, PAC 16, PAC 17 The essential accessories for multimeters

PAC 25, PAC 26, PAC 27 Measurement of AC/DC industrial currents

600 V CAT III

300 V CAT IV

400 A AC

600 A DC

AUTO POWER OFF

OFF

Zero

PAC 15

AC/DC CURRENT CLAMP

1 mV/A

Effectiveness in your hand

PAC Series

h If the clamp is no longer in use, it shuts

down automatically. The automatic power-

off function can be deactivated.

h For intensive use or to record measurements

over a long period, the PAC clamp can be

dc power pack

via its µUSB connector. If the external power

source cuts out temporarily, the battery

takes over.

The PAC clamps are

designed to optimize

safety. They fulfil the most

demanding criteria in the

current norms, including

IEC61010-2-032 for

industrial environments.

These models complete

the wide range of

ChauvinArnoux current

clamps made in France

at the Group's

ISO9000-certified

production plants.
