To order Reference
PAC17 AC/DC current clamp for oscilloscope with User's Manual and battery P01120117
Série MN
Pinces ampèremétriques pour courant AC
Non-contractual document
906200083 - Ed 1
12.04 (4/4)
PAC Series
AC/DC current clamp
(1)
Conditions of reference:
- Temperature & humidity: 23 °C ± 5 °K, 20 % to 75 % HR
- Power supply: by 6 V and 9 V battery or µUSB 5 ±0.1 V DC,
- Conductor position centred on the clamp locators
- Magnetic field: DC earth field
- Absence of any external alternating magnetic fields.
- Absence of electric fields
- Measurement for a current from DC to 65 Hz sinusoidal
- Impedance of the measuring instrument: > 1 MΩ ≤ 100 pF.
(2) (3)
Phase shift "absolute value" (unsigned)
(4)
Outside the reference domain
CURVES
Pulse response
PAC17 model (Isolated AC/DC current sensor)
