• Single Unit • Инверторный чиллер с возд. охлажд., станд. эффект, с низким уровнем шума • EWAD-BZSL
1
6
• Hydronic Systems • Single Unit
20
6 Таблицы производительности
6 - 2 Таблицы холодопроизводительности
EWAD-BZSS/SL
SRC_1-2-3-4-5_Rev.01_1-2
Ta: Condenser inlet air temperature; Twout: Evaporator leaving water temperature (ǻt 5°C);
CC: Cooling capacity; PI: Power input; qw: Fluid flow rate; dpw: Fluid pressure drop
Condenser
inlet air
temperature
Ta
Twout
5 7 9 11 13 15
CC PI qw dpw CC PI qw dpw CC PI qw dpw CC PI qw dpw CC PI qw dpw CC PI qw dpw
Size
kW kW l/s kPa kW kW l/s kPa kW kW l/s kPa kW kW l/s kPa kW kW l/s kPa kW kW l/s kPa
330
25
340.0 98.3 16.20 42.7 361.0 101.0 17.30 47.8 383.0 103.0 18.40 53.2 405.0 105.0 19.50 59.1 429.0 108.0 20.60 65.5 453.0 111.0 21.80 72.4
30
325.0 108.0 15.50 39.4 345.0 110.0 16.50 44.1 366.0 113.0 17.60 49.2 388.0 116.0 18.60 54.6 410.0 119.0 19.70 60.5 433.0 122.0 20.80 66.8
35
308.0 118.0 14.70 35.9 328.0 121.0 15.70 40.1 348.0 124.0 16.70 44.8 368.0 127.0 17.70 49.7 389.0 130.0 18.70 55.0 411.0 134.0 19.80 60.7
36
305.0 121.0 14.60 35.1 324.0 123.0 15.50 39.3 344.0 126.0 16.50 43.8 364.0 130.0 17.50 48.7 385.0 133.0 18.50 53.9 406.0 136.0 19.50 59.4
40
290.0 131.0 13.80 32.0 308.0 134.0 14.70 35.8 326.0 137.0 15.60 39.9 346.0 140.0 16.60 44.3 365.0 144.0 17.50 49.0 376.0 139.0 18.10 51.7
45
244.0 121.0 11.60 23.5 249.0 113.0 11.90 24.5 257.0 107.0 12.30 25.9 264.0 103.0 12.70 27.3 267.0 95.1 12.80 27.9 273.0 89.9 13.10 29.0
360
25
372.0 111.0 17.80 39.4 395.0 114.0 18.90 44.0 419.0 117.0 20.10 49.0 443.0 120.0 21.30 54.3 469.0 123.0 22.50 60.1 494.0 126.0 23.80 66.4
30
355.0 122.0 17.00 36.2 377.0 125.0 18.10 40.5 400.0 128.0 19.20 45.0 423.0 131.0 20.30 49.9 447.0 135.0 21.50 55.2 471.0 138.0 22.70 60.8
35
336.0 134.0 16.10 32.7 357.0 137.0 17.10 36.6 378.0 141.0 18.10 40.7 400.0 144.0 19.20 45.1 423.0 148.0 20.30 49.9 445.0 152.0 21.40 54.9
36
332.0 137.0 15.90 32.0 352.0 140.0 16.90 35.8 374.0 143.0 17.90 39.8 395.0 147.0 19.00 44.1 417.0 151.0 20.00 48.7 438.0 154.0 21.10 53.3
40
314.0 149.0 15.00 29.0 331.0 149.0 15.80 31.9 344.0 146.0 16.50 34.3 358.0 143.0 17.20 36.9 372.0 140.0 17.80 39.6 380.0 133.0 18.30 41.3
45
246.0 117.0 11.80 18.7 253.0 111.0 12.10 19.7 259.0 104.0 12.40 20.5 265.0 98.2 12.70 21.4 272.0 93.8 13.00 22.5 276.0 88.0 13.20 23.1
400
25
409.0 120.0 19.50 46.5 434.0 123.0 20.80 52.0 460.0 126.0 22.10 57.9 487.0 129.0 23.40 64.2 515.0 133.0 24.70 71.1 544.0 136.0 26.20 78.8
30
391.0 132.0 18.70 42.9 415.0 135.0 19.90 47.9 440.0 139.0 21.10 53.4 466.0 142.0 22.40 59.2 492.0 146.0 23.70 65.5 519.0 149.0 25.00 72.3
35
370.0 145.0 17.70 39.0 394.0 148.0 18.80 43.6 417.0 152.0 20.00 48.5 442.0 156.0 21.20 53.8 466.0 160.0 22.40 59.5 492.0 164.0 23.70 65.6
36
366.0 148.0 17.50 38.1 389.0 151.0 18.60 42.6 412.0 155.0 19.80 47.5 436.0 159.0 20.90 52.7 461.0 163.0 22.10 58.2 486.0 167.0 23.40 64.1
40
348.0 161.0 16.60 34.7 369.0 164.0 17.70 38.8 391.0 168.0 18.70 43.1 414.0 172.0 19.90 47.8 426.0 166.0 20.50 50.5 435.0 157.0 20.90 52.5
45
284.0 139.0 13.60 24.1 290.0 129.0 13.90 25.1 298.0 123.0 14.30 26.5 306.0 117.0 14.70 27.8 313.0 111.0 15.00 28.9 319.0 104.0 15.30 29.9
420
25
439.0 130.0 21.00 42.9 466.0 133.0 22.30 47.9 494.0 136.0 23.70 53.3 523.0 140.0 25.10 59.2 552.0 144.0 26.60 65.5 584.0 147.0 28.10 72.4
30
419.0 142.0 20.00 39.5 445.0 146.0 21.30 44.1 472.0 150.0 22.60 49.1 499.0 154.0 24.00 54.5 528.0 158.0 25.40 60.3 556.0 162.0 26.80 66.4
35
397.0 157.0 19.00 35.8 422.0 160.0 20.20 40.0 447.0 164.0 21.40 44.5 473.0 169.0 22.70 49.4 499.0 173.0 24.00 54.6 526.0 178.0 25.30 60.1
36
392.0 160.0 18.70 35.0 416.0 164.0 19.90 39.1 442.0 168.0 21.20 43.5 467.0 172.0 22.40 48.3 493.0 176.0 23.70 53.3 520.0 181.0 25.00 58.8
40
372.0 174.0 17.80 31.8 395.0 178.0 18.90 35.5 418.0 182.0 20.00 39.4 437.0 180.0 20.90 42.7 446.0 171.0 21.40 44.5 455.0 161.0 21.90 46.1
45
295.0 142.0 14.10 21.0 304.0 134.0 14.60 22.2 313.0 127.0 15.00 23.4 319.0 120.0 15.30 24.2 326.0 113.0 15.60 25.2 331.0 106.0 15.90 25.9
460
25
475.0 138.0 22.70 40.1 505.0 141.0 24.20 44.8 535.0 144.0 25.70 50.0 567.0 148.0 27.20 55.6 600.0 151.0 28.80 61.6 633.0 155.0 30.50 68.0
30
454.0 151.0 21.70 36.9 482.0 154.0 23.10 41.3 512.0 158.0 24.50 46.1 542.0 162.0 26.00 51.2 574.0 166.0 27.60 56.8 606.0 170.0 29.10 62.7
35
430.0 165.0 20.60 33.5 458.0 169.0 21.90 37.6 486.0 174.0 23.30 41.9 514.0 178.0 24.70 46.6 544.0 182.0 26.10 51.6 574.0 187.0 27.60 56.9
36
425.0 169.0 20.30 32.8 452.0 173.0 21.60 36.8 480.0 177.0 23.00 41.0 508.0 181.0 24.40 45.6 537.0 186.0 25.80 50.5 567.0 190.0 27.30 55.7
40
403.0 183.0 19.30 29.9 429.0 187.0 20.50 33.4 455.0 191.0 21.80 37.3 482.0 196.0 23.10 41.4 505.0 197.0 24.30 45.1 516.0 187.0 24.80 46.9
45
335.0 165.0 16.00 21.4 347.0 157.0 16.60 22.7 353.0 147.0 16.90 23.6 363.0 140.0 17.40 24.8 367.0 130.0 17.60 25.3 374.0 122.0 18.00 26.3
490
25
505.0 148.0 24.10 45.4 536.0 152.0 25.70 50.7 568.0 155.0 27.30 56.4 602.0 159.0 28.90 62.7 637.0 163.0 30.60 69.5 673.0 167.0 32.40 76.9
30
483.0 162.0 23.10 41.8 513.0 166.0 24.60 46.8 544.0 170.0 26.10 52.1 576.0 175.0 27.60 57.8 608.0 179.0 29.20 64.0 642.0 184.0 30.90 70.7
35
458.0 178.0 21.90 38.0 486.0 183.0 23.30 42.5 516.0 187.0 24.70 47.3 546.0 192.0 26.20 52.5 577.0 197.0 27.70 58.1 608.0 202.0 29.30 64.0
36
452.0 182.0 21.60 37.2 481.0 186.0 23.00 41.6 510.0 191.0 24.40 46.3 539.0 195.0 25.90 51.4 570.0 200.0 27.40 56.8 601.0 206.0 28.90 62.6
40
429.0 198.0 20.50 33.9 456.0 202.0 21.80 37.8 483.0 206.0 23.20 42.1 512.0 211.0 24.50 46.7 533.0 210.0 25.60 50.4 544.0 199.0 26.20 52.4
45
352.0 173.0 16.80 23.7 364.0 164.0 17.40 25.1 374.0 156.0 17.90 26.5 380.0 145.0 18.20 27.3 389.0 137.0 18.60 28.5 396.0 130.0 19.00 29.5
520
25
533.0 158.0 25.50 50.0 566.0 162.0 27.10 55.9 600.0 166.0 28.80 62.2 635.0 170.0 30.50 69.0 672.0 174.0 32.30 76.6 711.0 179.0 34.20 84.8
30
510.0 173.0 24.40 46.1 541.0 177.0 25.90 51.5 574.0 182.0 27.50 57.3 607.0 186.0 29.10 63.6 641.0 191.0 30.80 70.3 677.0 196.0 32.60 77.8
35
483.0 190.0 23.10 41.9 513.0 195.0 24.60 46.8 544.0 200.0 26.10 52.1 575.0 205.0 27.60 57.7 608.0 210.0 29.20 63.8 640.0 215.0 30.80 70.3
36
477.0 194.0 22.80 41.0 507.0 199.0 24.30 45.8 537.0 204.0 25.80 51.0 568.0 209.0 27.30 56.5 600.0 214.0 28.80 62.4 633.0 220.0 30.40 68.7
40
453.0 212.0 21.70 37.3 481.0 216.0 23.00 41.6 509.0 220.0 24.40 46.2 539.0 226.0 25.90 51.3 555.0 218.0 26.70 54.2 566.0 206.0 27.20 56.2
45
367.0 179.0 17.50 25.5 378.0 170.0 18.10 27.0 389.0 161.0 18.60 28.5 395.0 149.0 18.90 29.2 403.0 141.0 19.30 30.4 410.0 133.0 19.70 31.4
